Overview
Place of Origin: |
USA |
Brand Name: |
Reliance Electric |
Model Number: |
UVZC3407G |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Dimensions: |
7.5x30x43cm |
|
Weight: |
4.08 kg |
|
Series: |
VZ3000 Series |
|
Product Type: |
3‑Phase AC Servo Drive / Inverter Unit |
|
Input Voltage: |
380/400/440/460 VAC, 3‑phase |
|
Input Frequency: |
50/60 Hz |
|
Power Rating: |
7.5 kW |
|
Output DC Bus Voltage: |
460‑715 VDC |
|
Control Method: |
IGBT Sinusoidal PWM Full Digital Vector Control |
|
Enclosure Type: |
Chassis Mount Drive |
|
Cooling Method: |
Built‑in cooling fan (runs during operation) |
|
Main Terminals: |
L1(R), L2(S), L3(T), P, N, U, V, W, G |
Description
The UVZC3407G from Reliance Electric is a 3Phase AC Servo Drive designed for precise industrial automation control. Measuring 7.5×30×43 cm and weighing 4.08 kg, the UVZC3407G supports 380–460 VAC input at 50/60 Hz and delivers 7.5 kW output with a 460–715 VDC bus. Using IGBT Sinusoidal PWM Full Digital Vector Control, the UVZC3407G efficiently drives motors via main terminals L1, L2, L3, U, V, W, and G, while control terminals GF2, GF1, and others manage system signals. Equipped with a 7segment LED display, X10/X1 drop switches, and P/S, RDY, RUN, COM lamps, the UVZC3407G provides clear operational feedback. Communication is enabled through CN1–CN5 ports, and the unit allows regenerative resistor connection. Built-in cooling ensures the UVZC3407G maintains performance during continuous operation, making it ideal for automated conveyor, robotics, and material handling systems.
Applications
Metalworking and Steel Plants: Used for power drives in rolling mills, wire drawing machines, and large conveyor systems to control speed synchronization during metal forming processes.
Oil & Gas: Used for speed control of large pump sets, slurry pumps, and centrifuges to ensure stable power in continuous operating environments.
Pulp & Paper Industry: Used to drive synchronous motors in large papermaking production lines to ensure constant paper tension in drying cylinders or press sections.
Rubber and Plastics Processing: Used for starting and speed regulation of heavy equipment such as large extruders and internal mixers.
Mining and Material Handling: Drives large mining belt conveyors, elevators, or mills.
Specifications
|
Control Terminals: |
GF2, GF1, IP, RDY, OPE, 0VC, +VC, FR2, FR1 |
|
Display Indicators: |
P/S, RDY, RUN, COM lamps |
|
User Interface: |
7‑segment LED monitor, X10 and X1 drop switches |
|
Communication Ports: |
Comm.1 (CN4), Comm.2 (CN3), Comm.3 (CN5) |
|
Control Signal Port: |
CN2 |
|
PG Frequency Divider Port: |
CN9 |
|
PG Input Port: |
CN1 |
|
Regenerative Resistor Connection: |
Supported via dedicated terminals |
Competitive Advantage
Competitive Advantage Fast Response Control
The UVZC3407G’s IGBT PWM vector control delivers response times under 5 ms, enabling rapid adjustment to changing motor loads up to 7.5 kW without overcurrent trips.
Competitive Advantage Integrated Feedback Handling
The UVZC3407G supports encoder inputs via CN1 and CN9, allowing precise speed measurement up to 10 kHz signal frequency and real-time correction to maintain motion accuracy.
Competitive Advantage Operational Monitoring
The UVZC3407G includes 7segment LED and P/S, RDY, RUN, COM indicators for continuous monitoring of input voltage (380–460 VAC), DC bus voltage (460–715 VDC), and drive status, simplifying fault detection.
Competitive Advantage Efficient Power Management
The UVZC3407G supports regenerative resistor connections, enabling up to 7.5 kW energy return to the bus during deceleration cycles, reducing system energy consumption by up to 15 % in continuous operation.
