3500/93 135799-02 Display Interface Module

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	3500/93 135799-02
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The 3500/93 135799-02 Display Interface Module from Bently Nevada™ provides local or remote visual indication of all 3500 Machinery Protection System data, including system events, alarm events, and channel, monitor, relay, Keyphasor®, or tachometer module values. The 3500/93 135799-02 supports RS422 communication and Bently Nevada proprietary protocol or Modbus®, with a 1-second typical channel update rate. Operating from -30°C to +65°C and storing safely up to +85°C with 95% non-condensing humidity, the 3500/93 135799-02 is suitable for industrial automation environments. Power consumption ranges from 5.6 W for -01 Display Units to 12.0 W for -02 Display Units, with a maximum of 15.5 W including the main module. The module occupies 1 full-height front slot for the main board and 1 full-height rear slot for I/O modules. LEDs indicate operational status (OK) and active communication (TX/RX) with 3500 rack modules. The 3500/93 135799-02 can be face-mounted, 19-inch rack-mounted, panel-mounted, or independently mounted up to 100 feet from the 3500 System (4000 feet with External Power Supply), supporting high-density automation systems. The Configurable Display Interface enables real-time monitoring and efficient integration of multiple rack channels, allowing operators to access system data quickly and maintain continuous industrial process control.

Applications

Oil & Gas: In refineries and offshore platforms, the 3500/93 module locally displays vibration and displacement values for compressors and turbines, ensuring field operators can immediately identify alarm causes.

Power Generation: Provides critical "system event list" and "alarm list" near gas turbines or steam turbine units, helping engineers conduct rapid accident analysis after a trip.

Petrochemical: Used for monitoring large reactor agitators and pump units, serving as a local safety backup display outside the DCS central control room.

Heavy Machinery Manufacturing: Serves as a core data aggregation and local visualization component in protection systems for large fans, blowers, and reciprocating machinery.

Specifications

Competitive Advantage

Enable Precise Data Mapping

The 3500/93 135799-02 interfaces with 3500 Rack Configuration Software, allowing exact mapping of monitored values and alarms. Its 1-second channel update rate and high-speed internal network ensure that operators receive accurate real-time information for process control integration.

Simplify Rack Installation

The 3500/93 135799-02 offers multiple mounting options and uses only 1 full-height front slot for the main board and 1 full-height rear slot for I/O modules. This allows deployment in high-density racks without interfering with other modules or connections.

Provide Immediate Operational Feedback

The 3500/93 135799-02 uses OK and TX/RX LEDs to give operators instant feedback on communication and module status. Combined with 5.6–12 W power consumption and -30°C to +65°C operating temperature, this ensures reliable, continuous operation in industrial environments.

Support Multi-Display High-Density Monitoring

Up to two 3500/93 135799-02 displays can connect to a single 3500 rack, allowing operators to monitor multiple channels simultaneously. With External Power Supply and Cable Adapter support, the 3500/93 135799-02 enables long-distance installations up to 4000 feet, maintaining continuous automation system oversight.
