Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	3500/61 136711-02
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Inputs Signal	Accepts from 1 to 6 RTD or TC transducer signals
Input Impedance	Greater than 10 MW for each lead input.
Tranducers	Isolated TC I/O modules have 250 Vdc of isolation between channels
Voltage Compliance (current output)	0 to +12 Vdc range across load. Load resistance is 0 to 600 W.
Resolution	0.3662 µA per bit ±0.15% error at room temperature ±0.4% error over temperature range.
Signal Conditioning	Full-scale range for each channel is set in the field via 3500 Configuration Software. No calibration is required
Operating Temperature	-30 °C to +65 °C (-22 °F to +150 °F) when used with Internal/External/Termination I/O Modules 0 °C to +65 °C (32 °F to +150 °F) when used with Internal Barrier I/O Modules (Internal Termination)
Dimension:	2.5x18.5x24.2cm
Weight:	0.98kg

Description

The 3500/61 136711-02 RTD/TC I/O Module provides six channels of automated temperature monitoring using RTD or Thermocouple inputs. The 3500/61 136711-02 conditions signals from 1 to 6 transducers, with input impedance greater than 10 MΩ per lead, and compares them to user-programmed alarm setpoints. Each channel delivers 4–20 mA recorder output proportional to full-scale temperature, with 0.3662 µA per bit resolution and ±0.4% error across the temperature range. The 3500/61 136711-02 supports RTD current sources at 925 ±15 µA and can be configured via 3500 Rack Configuration Software for RTD, TC, or mixed inputs. Isolated TC modules provide 250 Vdc channel-to-channel separation to reduce interference. Operating temperature ranges from -30°C to +65°C, and multiple 3500/61 136711-02 modules can be installed in Triple Modular Redundant (TMR) arrangements for automated voting logic, enabling precise alarm activation and continuous temperature data monitoring in industrial systems.

Applications

Monitor Industrial Equipment Temperature
The 3500/61 136711-02 accepts 1 to 6 RTD or Thermocouple signals, conditioning each channel and comparing it to programmed alarm setpoints. With 4–20 mA recorder output and 0.3662 µA per bit resolution, the 3500/61 136711-02 enables automated detection of high temperatures in turbines, pumps, and compressors.

Integrate Temperature Data into Control Systems
Each channel of the 3500/61 136711-02 outputs proportional current signals for SCADA or DCS systems, allowing automated cooling, shutdown, or alarm routines based on real-time temperature readings.

Configure Mixed RTD and TC Inputs
Using 3500 Rack Configuration Software, the 3500/61 136711-02 can measure RTD, TC, or mixed input types. Isolated TC modules provide 250 Vdc channel-to-channel separation, ensuring accurate readings in electrically noisy industrial environments.

Implement Triple Modular Redundant Voting
Three 3500/61 136711-02 modules installed adjacently in TMR arrangements allow automated voting logic for temperature alarms, preventing single-point failures in high-risk automated processes.

Specifications

Rack Space Requirements	1 full-height rear slot.
Internal Barrier I/O Module	Consult the 3500Internal Barrier specification sheet(part number 141495-01) if thelnternal Barrier Option is selected.
RTD Current Source Value	925 ±15 mA @ 25° C per transducer (single supply for the 4-wire RTD and two supplies for the 3-wire).
Recorder	+4 to +20 mA. Values are proportional to monitor full-scale. Individual recorder values are provided for each channel. Monitor operation is unaffected by short circuits on recorder outputs
Voltage Compliance (current output)	0 to +12 Vdc range across load. Load resistance is 0 to 600 W.
Resolution	0.3662 µA per bit ±0.15% error at room temperature ±0.4% error over temperature range.
RTDs and TCs (except for 10W Copper RTDs) Resolution	1°C or 1°F
Accuracy(Internal Termination Non-Isolated）	Bulkhead Rack ±3 °C at 25 °C (±5.4 °F at 77 °F)；Standard Rack: ±3 °C at 25 °C (±5.4 °F at 77 °F).

Competitive Advantage

Fast Alarm Activation with Quantified Accuracy
The 3500/61 136711-02 triggers automated alarms immediately when temperature thresholds are exceeded. Each channel supports ±0.4% error across its measurement range, enabling precise automated shutdown or alert actions.

High-Resolution Recorder Output
Each of the six channels on the 3500/61 136711-02 provides 4–20 mA output, with 0.3662 µA per bit resolution. This high-resolution output allows automated control systems to detect even minor temperature changes and execute corrective actions.

Supports Mixed RTD and TC Inputs with Electrical Isolation
The 3500/61 136711-02 accepts RTD, TC, or mixed signals. Isolated TC modules provide 250 Vdc channel-to-channel separation, reducing interference and ensuring reliable automated data collection in electrically noisy industrial environments.

Automated Triple Modular Redundant Voting
Three 3500/61 136711-02 modules installed in TMR configuration allow automated voting logic. This ensures that alarm decisions are based on consistent data from multiple channels, preventing false alarms and minimizing single-point failures.
