Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
10024/H/F |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
10024/H/F |
|
Part name |
Enhanced Communication Module |
|
Dimensions |
4x18.5x12.8cm |
|
Weight |
0.28 kg |
|
Input voltage |
5 V DC |
|
Input current |
500 mA |
|
Typical input power |
7 W |
|
Supported protocols |
RS232, RS422, RS485, Current Loop |
|
Certifications |
CE, RoHS |
Description
The 10024/H/F is an Enhanced COM module. It is equipped with a built-in main processor (int.CP) and a standard RS232 serial physical interface, responsible for establishing bidirectional data links between the central control system and external operator stations and third-party network nodes, transmitting readings from field measuring instruments, on/off status signals of control valves, and logic interlock execution data.
Applications
Chemical plants: Temperature data and shutdown valve control transmission.
Refineries: Pressure data transfer and monitoring network connection.
Power plants: Turbine status and emergency trip signal exchange.
Steel plants: Temperature control data between gas analyzer and furnace controller.
Maintenance Recommendations and Troubleshooting
Maintenance Recommendations: It is recommended to regularly check the grounding status of the shielding layer at the module interface and monitor the load rate of the communication link using diagnostic software to avoid prolonged overload operation.
Troubleshooting: If packet loss occurs, first check whether the terminal matching resistor is installed correctly; if the module is unresponsive, check whether the 5V power supply to the backplane is within the normal range.
FAQ
Q: What input voltage and current are required for the 10024/H/F module?
A: Input voltage 5 V DC, input current 500 mA.
Q: What is the typical input power of the 10024/H/F during operation?
A: Typical input power is 7 W.
Q: Which physical layer communication protocols are supported by the 10024/H/F module?
A: Supports RS232, RS422, RS485, and Current Loop.
Q: Which international environmental and safety certifications has the 10024/H/F module passed?
A: Passed CE and RoHS certifications.
Q: How much higher is the supply current of the 10024/H/F compared with the 10020/1/2 model?
A: Increased by 200 mA (from 300 mA to 500 mA).
