Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T8153C |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
T8153C |
|
Part Name |
Trusted Communication Interface |
|
Dimensions |
13.5 × 10.7 × 2.7 cm |
|
Weight |
0.4 kg |
|
Operating Voltage |
24 Vdc |
|
Power Consumption |
5 W |
|
Data Transfer Rate |
10 Mbps |
|
Number of Channels |
8 channels |
|
Interface Compatibility |
RS-485 |
|
Communication Protocol |
Modbus RTU |
|
Operating Temperature |
-20°C to +60°C |
Description
The ICS TRIPLEX T8153C Trusted Communication Interface is designed for industrial automation systems, offering enhanced connectivity and reliability for complex control applications.
Applications
Petrochemical Refineries: SIS communication cabinet collecting Modbus RTU signals from field devices.
Thermal Power Plants: Gateway unit ensuring real-time data transfer from auxiliary subsystems to DCS.
Steel Plants: Used in high-temperature environments for stable furnace and drive system monitoring.
Pipeline Stations: Low-power remote control for valve monitoring in unmanned stations.
Automotive Plants: High-density RS-485 networking for robotic and production line control systems.
Features
Triple Redundancy Design: Employs a triple modular redundancy (TMR) structure to ensure continued system operation even in the event of a single module failure.
High Reliability: Supports zero single point of failure; all critical components are triple-redundant.
Automatic Fault Detection and Isolation: Automatically detects and isolates faulty components, reducing mean time to repair (MTBL) and improving system availability.
Bump-Free Fault Handling: The system continues to provide control without delay or performance degradation during a failure.
FAQ
Q: Are the 8 channels of T8153C electrically isolated, and will a lightning fault affect other channels?
A: Yes. The 8 channels are fully independent with strong isolation, so a single-channel failure does not propagate.
Q: Can T8153C directly connect to legacy RS-485 power meters?
A: Yes. It natively supports standard RS-485 and connects directly to most industrial devices.
Q: What should be considered when using T8153C near its 10 Mbps communication rate?
A: Use shielded twisted pair cables, limit cable length, and install 120 Ω termination resistors.
Q: Will T8153C overheat at 55°C in a non-air-conditioned cabinet?
A: No. It operates from -20°C to +60°C with low 5W power consumption.
Q: Does T8153C support custom serial streaming protocols besides MODBUS RTU?
A: MODBUS RTU is standard; custom protocols require firmware-level configuration.
