6GK5205-3BD00-2AB2 SCALANCE XB205-3 Managed Industrial Ethernet Switch
The SCALANCE XB205-3 is a managed Layer 2 switch with five 10/100 Mbps RJ45 ports, three multimode 100BASE-FX SC ports, PROFINET diagnostics and redundant 24 V DC power.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6GK5205-3BD00-2AB2 |
| Product Type | Managed Layer 2 Industrial Ethernet switch |
| Core Function | Segments and manages plant Ethernet traffic |
| Application or Compatible Series | SCALANCE XB-200 managed industrial networks |
Exact Identification
Match 6GK5205-3BD00-2AB2 character by character and confirm the complete SCALANCE XB205-3 Managed Industrial Ethernet Switch designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The SCALANCE XB205-3 is a managed Layer 2 switch with five 10/100 Mbps RJ45 ports, three multimode 100BASE-FX SC ports, PROFINET diagnostics and redundant 24 V DC power.
Five electrical ports and three SC optical ports combine local device connections with fiber uplinks. PROFINET IO device functions, diagnostics and managed Layer 2 features support structured industrial networks. A compact IP20 housing with redundant power input installs on a standard DIN rail.
Key Functions
Copper and Multimode Fiber
Five electrical ports and three SC optical ports combine local device connections with fiber uplinks.
Managed Automation Networking
PROFINET IO device functions, diagnostics and managed Layer 2 features support structured industrial networks.
Compact DIN-Rail Hardware
A compact IP20 housing with redundant power input installs on a standard DIN rail.
Official Specifications
| Electrical Ethernet Ports | 5 x RJ45 |
|---|---|
| Electrical Port Rate | 10/100 Mbps |
| Optical Ports | 3 x multimode SC |
| Optical Transmission Method | 100BASE-FX |
| Console Interface | 1 x RJ11 |
| Rated Supply | 24 V DC with redundant input |
| Current Consumption at 24 V DC | 290 mA |
| Effective Power Loss | 7 W |
| Input Fusing | F 2.5 A / 125 V |
| Operating Temperature | 0 to +60 °C |
| Storage and Transport Temperature | -40 to +70 °C |
| Maximum Operating Humidity | 95 % at 25 °C, non-condensing |
| Degree of Protection | IP20 |
| Dimensions | 80 x 117 x 109 mm |
| Weight | 350 g |
| Mounting | DIN rail |
| MTBF at 40 °C | Greater than 50 years |
Frequently Asked Questions
Which fiber connectors should I use with 6GK5205-3BD00-2AB2?
Use compatible multimode fiber with SC connectors for the three 100BASE-FX optical ports.
Can 6GK5205-3BD00-2AB2 connect ordinary copper Ethernet devices?
Yes; five RJ45 ports provide 10 or 100 Mbps electrical Ethernet connections.
How should redundant power be wired to 6GK5205-3BD00-2AB2?
Connect the two documented 24 V DC feeds and verify the supply monitoring and protective device.
Which engineering protocol should I configure for 6GK5205-3BD00-2AB2?
Use its PROFINET IO device functions when the automation project requires controller diagnostics.
What environmental limit applies to 6GK5205-3BD00-2AB2?
Operate the switch between 0 and +60 °C with non-condensing humidity within the stated limit.
What configuration should I retain before exchanging 6GK5205-3BD00-2AB2?
Save the switch configuration, PROFINET name, IP address, VLANs, redundancy settings and port assignments.
What should I check after installing 6GK5205-3BD00-2AB2?
Verify both power inputs, all copper and fiber links, port diagnostics, management access and the configured redundancy behavior.
