IC670GBI102 bus interface unit

Overview

Place of Origin:	USA
Brand Name:	GE
Model Number:	IC670GBI102
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Description

The IC670GBI102 bus interface unit is a Field Control bus interface unit manufactured by GE Fanuc. The unit is part of the GE Field Control series and it is compatible with the IC670GB and IC670GBI modules. This programmable control module operates within a temperature range of 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) and it has a storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The relative humidity range of the IC670GBI102 bus interface module is 5 to 95% (non-condensing). The IC670GBI102 bus interface unit can withstand a solid vibration and shock levels that are typical for industrial environments and it is installed on panel-mounted DIN rail. The IC670GBI102 bus interface unit can operate on both AC and DC power sources and the operating voltage range is 90 to 135 Volts AC and 105 to 150 Volts DC. The nominal rated voltage of the IC670GBI102 bus interface unit is 115 Volts AC and 125 Volts DC. The power consumption is a maximum of 48 Volt-Amps at 115 Volts AC and a maximum of 24 Watts at 125 Volts AC. The power consumption is specified for operation on a full load. The inrush current of the unit is 20 Amps at peak for a maximum of 3 milliseconds. The maximum holdup time of the unit is 20 milliseconds while the power supply output voltage is 6.5 Volts DC. The input frequency of the unit is 47 to 63 Hertz. The terminal block of the bus interface unit is 16 milliamps and its reliability rating is more than 600,000 hours.

Applications

Water Treatment and Environmental Protection: Widely used in distributed I/O monitoring of wastewater treatment plants, processing signals from dispersed sensors.

Power and Energy: Used in automated control systems for power plants, substations, and water conservancy projects.

Petroleum and Chemical Industry: Responsible for remote signal acquisition in oil refining, natural gas extraction, and fine chemical production lines.

Manufacturing and Heavy Industry: Includes factories in automobile manufacturing, steel metallurgy, papermaking and printing, textile dyeing, and plastics machinery.

Municipal Engineering: Such as urban heating systems and water supply and drainage monitoring.

Key Features

1 Power Compatibility: The BlU operates on a 24VDC power source. It features advanced internal overvoltage protection, ensuring safe operation under varying power conditions.

2 Scalability: The BlU supports up to four I/O terminal blocks, offering flexibility for expanding system configurations.

3 Noise Immunity: Built with enhanced noise immunity, the BlU is well-suited for environments prone to electrical interference.

4 Hot-Swap Support: Allows for hot insertion and removal of compatible I/O modules without powering down the system, provided certain terminal block requirements are met.

Mounting

The BlU terminal block must be mounted on a 7.5mm x 35mm DIN rail that has a conductive finish to ensure proper grounding. Proper mounting is crucial for stable

operation, and the following considerations should be observed:

1 Spacing Requirements: To facilitate easy access to the wiring and ensure proper airflow, it is recommended to mount the unit at least 4.25 inches (10.80 cm) away from wireways or any other obstructions. This clearance helps maintain sufficient space for wire connections and reduces the risk of damage or overheating.

2 Grounding: The DIN rail must be properly grounded to ensure the unit's optimal performance. Note that the BlU is not compatible with older "A version" I/O terminal blocks that lack a metal grounding strip. Proper grounding ensures safety and minimizes the risk of electrical interference.

3 Vibration Resistance: To increase the stability of the mounted rail, use screws to secure it in place, spaced approximately 6 inches (5.24 cm) apart. For added vibration resistance, it is recommended to drill mounting holes for the terminal block's mounting ears, ensuring a more secure and stable attachment to the rail.

FAQ

Q: Does the IC670GBI102 come with a warranty?
A: Yes, the IC670GBI102 includes a 1-year warranty.

Q: What is the difference between the IC670GBI102 and the IC670GBI002?
A: The IC670GBI102 is powered by an input voltage of 115 VAC / 125 VDC, while the IC670GBI002 is powered by 24 VDC.

Q: Does the IC670GBI102 support insertion and removal of modules under power?
A: Yes, provided the modules have the suffix "J" on their catalog number.

Q: What is the reliability of the IC670GBI102?
A: The IC670GBI102 has a reliability of more than 183,000 hours operation MTBF, calculated.

Q: What is the data size that can be handled by the IC670GBI001?
A: Supported data sizes are 256 Bytes for discrete inputs (%I), status data and intelligent modules; 256 Bytes for discrete outputs (%Q) and fault clearing for intelligent modules; 256 Bytes for analog inputs (%AI); and 256 Bytes for analog outputs (%AQ).

Q: What are the data transmission speeds supported by the IC670GBI001?
A: The IC670GBI001 supports 53.6 Kbaud standard, 153.6 Kbaud extended, 76.8 Kbaud, or 38.4 Kbaud.

Q: Does the IC670GBI001 support redundancy?
A: Yes, the IC670GBI001 has built-in support for network redundancy.
