Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
DS200CPCAG1ABB |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Manufacturer: |
GE |
|
Part Number: |
DS200CPCAG1ABB |
|
Product Type: |
Contactor Guide Card |
|
Series: |
Mark V |
|
Dimensions: |
10.2 x 8.8 x 5.4 cm |
|
Weight: |
0.12 kg |
|
Connectors: |
12-pin connector and two 2-pin connectors |
|
Terminal Blocks: |
Four terminals, supports up to 12 signal lines |
|
Input Channels: |
12 |
|
Output Rating: |
125 V DC |
|
Trip Solenoid Rating: |
125 V DC |
|
Power Supply Voltage: |
28 V DC |
|
Voltage Range: |
18–32 V DC |
|
Mounting: |
DIN-rail mounting |
|
Technology: |
Surface mount |
|
Operating Temperature: |
40 to 70°C |
Description
The DS200CPCAG1ABB is a contactor guide card manufactured by GE. It is primarily used to secure and guide auxiliary contact blocks within a contactor, ensuring the correct positioning of the auxiliary contact blocks inside the contactor and providing a reliable electrical connection.
Applications
The DS200CPCAG1ABB is widely used in various industrial automation equipment, such as:
Motor control system: Used to control the starting, stopping, and direction of the motor.
Automated production line: Used to control the operation of various automated equipment.
Power system: Used to control the on/off state of electrical equipment.
Features
Precise guidance: The guide card is precisely designed to guide the auxiliary contact block accurately, ensuring accurate and reliable engagement between it and the main contact.
Good insulation: Made of high-quality insulating materials, it has good insulation performance and prevents short circuits and leakage.
High temperature resistance: It can withstand high temperature environments and is suitable for various harsh working conditions.
Easy to install: The design is reasonable, and installation is simple and quick.
Functions
Fixed auxiliary contact block: Fix the auxiliary contact block in a designated position inside the contactor.
Guide auxiliary contact block: Guide the auxiliary contact block to move accurately and ensure good contact with the main contact.
Provides electrical connection: A reliable connection between the auxiliary contact block and external circuitry is provided via the terminal blocks on the guide card.
Structure
The structure of DS200CPCAG1ABB typically includes the following parts:
Guide groove: Used to guide the movement of auxiliary contact blocks.
Fixing hole: Used to fix the guide card to the contactor.
Terminal blocks: Used to connect auxiliary contact blocks and external circuits.
FAQ
Q: How do I find the capacitor on DS200CPCAG1ABB?
A: The capacitor on DS200CPCAG1ABB is located in the center of the board and is dark red in color.
Q: How many amps are on DS200CPCAG1ABB?
A: DS200CPCAG1ABB supports 10 amps at 250 volts and 10 amps at 30 volts.
Q: What are the dimensions of DS200CPCAG1ABB?
A: DS200CPCAG1ABB measures 10.2 × 8.8 × 5.4 cm.
