Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
CT/VT8H UR8HH |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
CT/VT8H UR8HH |
|
Dimensions |
4x18.3x17.1cm |
|
Weight |
1.2kg |
|
Processor type |
80386EX |
|
Processing speed |
25 MHz |
|
Operating temperature range |
0°C to 60°C (32°F to 140°F) |
|
Scan rate |
0.22 ms/K (typical) |
|
User program memory |
32 KB (max) |
Description
The CT/VT8H UR8HH is a high-precision CT/VT module designed specifically for relay protection and power monitoring systems. As the sensing core of substation automation and feeder protection systems, this module can capture analog signals from current transformers (CTs) and voltage transformers (VTs) in real time and convert them into high-speed digital streams that the system can recognize.
Applications
Intelligent Substation Plants: Collect busbar and feeder data for protection systems.
Heavy Industrial Power Plants: Monitor high-voltage motor status to prevent electrical faults.
Wind Power Plants: Monitor turbine output quality and support grid protection control.
Petrochemical Power Plants: Provide continuous monitoring for early fault detection and isolation.
Features
High Reliability: Employs industrial-grade components and design, ensuring reliable operation in harsh environments.
Sensitive Grounding Function: Allows the relay to proportionally reduce its current and voltage ratings.
Comprehensive Protection Function: In addition to basic protection functions, it provides protection against special fault types, such as resonant overvoltage and transient overcurrent.
Software Integration
EnerVista UR Software: Enables efficient configuration and data visualization
EnerVista Viewpoint UR Engineer: Drag-and-drop environment for rapid commissioning
Interface: Provides a user-friendly and well-organized display for settings and data review
FAQ
Q: How does the CT/VT8H UR8HH ensure real-time power system performance via the 80386EX core?
A: It uses the 80386EX industrial processor to deliver stable computing power and fast instruction response for current and voltage signal processing.
Q: Is the 25MHz processing speed of the CT/VT8H UR8HH sufficient for rapidly changing power faults?
A: Yes. Optimized acquisition logic and instruction design ensure accurate sampling and fast fault identification.
Q: What does the 0.22 ms/K scan rate of the CT/VT8H UR8HH improve in fault detection?
A: It enables extremely fast program scanning, allowing near-instant protection response to grid anomalies.
Q: What protection algorithms can the 32KB memory of the CT/VT8H UR8HH support?
A: It stores complex compensation and fault recording logic for customizable protection strategies.
Q: How does the CT/VT8H UR8HH maintain sampling accuracy from 0–60°C?
A: A temperature compensation circuit stabilizes core operation, ensuring consistent and reliable data output.
