Overview
330130-040-01-05 3300 XL Standard Extension Cable
At a Glance
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330130-040-01-05 |
Minimum Order Quantity: |
1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Product Overview
Description
The 330130-040-01-05 3300 XL Standard Extension Cable serves as a vital connectivity part, crafted to extend the operational range of 3300 XL proximity transducer systems while preserving uncompromised signal transfer between 3300 XL probes and Proximitor sensors in industrial monitoring configurations. As a key member of the 3300 XL product lineup, this extension cable is instrumental in sustaining the system’s core functionality: delivering output signals that bear a direct proportional relationship to the gap between the probe tip and target conductive surfaces. It thereby enables precise capture of both static positional information and dynamic vibration readings—whether utilized in fluid-film bearing machinery for vibration and position tracking, or as an essential link in Keyphasor reference and speed measurement setups. Throughout all these applications, the 3300 XL Standard Extension Cable upholds the stringent performance standards that define the 3300 XL transducer family.
Tailored to complement the advanced capabilities of 3300 XL proximity transducer systems, the 330130-040-01-05 3300 XL Standard Extension Cable meets the same rigorous performance criteria, including full conformance to the American Petroleum Institute’s (API) 670 Standard. This compliance encompasses critical areas like mechanical resilience, signal transmission precision, thermal stability, and structural compatibility—making it a seamless fit for oil & gas, power generation, and petrochemical applications where API certification is a must. What distinguishes the 3300 XL Standard Extension Cable is its ability to boost system flexibility: by lengthening the effective reach of 3300 XL probes, it facilitates installation in large-scale equipment or hard-to-access spots (such as deep turbine casings or remote pump housings) where direct wiring between probes and Proximitor sensors would be unfeasible.
Key Functions
Applications
The 330130-040-01-05 3300 XL Standard Extension Cable is a rugged, high-performance connectivity solution engineered to extend signal transmission for 3300 XL proximity transducer systems across diverse industrial environments. Leveraging its core parameters—including global CSA, ATEX, IECEx explosion-proof certifications, armored cable protection, ultra-wide temperature tolerance, and stable signal performance—it excels in critical applications spanning key industries, ensuring reliable connectivity even in harsh operating conditions.In the oil & gas industry, it is ideal for connecting 3300 XL probes to Proximitor sensors in oil refineries, offshore drilling platforms, and natural gas processing plants—where explosive atmospheres and harsh conditions demand certified safety and durability. The cable’s CSA, ATEX, and IECEx approvals ensure compliance with global hazardous area standards, while the armored cable design resists physical damage from oil spills, mechanical abrasion, and outdoor elements. With a 4.0-meter (13.1-foot) length and 75Ω triaxial construction, it maintains signal integrity over extended distances, supporting precise vibration, position, and Keyphasor measurements for pumps, compressors, and turbines. The -52°C to +177°C (-62°F to +350°F) operating temperature range adapts to frigid offshore winters and high-heat refining processes, while the 69.9 pF/m typical capacitance minimizes signal drift—critical for maintaining the system’s 2 mm (80 mils) linear range accuracy in critical production lines.For power generation, the cable is critical for thermal, nuclear, and combined-cycle power plants to link 3300 XL probes with control systems in steam turbines, generators, and boiler feed pumps. The armored cable withstands high vibration and mechanical stress in turbine rooms, preventing cable damage from equipment movement or maintenance activities.
Official Specifications
Quick Detail
|
Agency Approval Option: |
CSA, ATEX, IECEx Approvals |
|
Connector Protector and Cable Option : |
Armored cable |
|
Cable Length Option: |
4.0 meters (26.2 feet) |
|
Dimension: |
1.5x1.3x113cm |
|
Weight: |
0.14kg |
Specifications
|
Operating Temperature Range: |
-52°C to +177°C (-62°F to+350°F) |
|
Linear Range: |
2 mm (80 mils) |
|
Output Resistance: |
50 Ω |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Standard cable: |
75Ω triaxial |
|
Probe Tip Material: |
Polyphenylene sulfide (PPS) |
|
Extension Cable Capacitance: |
69.9 pF/m (21.3 pF/ft)typical |
|
Field Wiring: |
0.2 to 1.5 mm2 (16 to 24AWG) |
Frequently Asked Questions
What is the model number?
The listed model number is 330130-040-01-05.
What is the brand name?
The listed brand name is Bently Nevada.
What is the place of origin?
The listed place of origin is USA.
What are the packaging details?
The listed packaging details are Original new Factory Sealed.
What is the delivery time?
The listed delivery time is 5-7 days.
Is this model available?
The listed supply status is In stock.
What are the payment terms?
The listed payment terms are T/T.
Compatibility & Ordering Notes
Competitive Advantage
1. Armored Construction for Rugged Environment Resilience
Featuring a reinforced armored cable design, the extension cable withstands physical damage, chemical spills, abrasive debris, and mechanical wear—critical for harsh industrial settings. Paired with a polyphenylene sulfide (PPS) probe tip interface (compatible with 3300 XL probes), it resists corrosion from hydrocarbons, chemicals, and saltwater, extending service life in demanding environments where standard cables fail prematurely. The rugged build also protects against accidental impact during maintenance or equipment operation.
2. Ultra-Wide Temperature Range for Extreme Conditions
Boasting an operating temperature range of -52°C to +177°C (-62°F to +350°F), the cable outperforms standard extension cables limited to narrower temperature bands. It maintains stable signal transmission in frigid offshore winters, high-heat turbine rooms, and fluctuating chemical processing environments—ensuring consistent performance without signal degradation or structural damage, even in extreme thermal stress.
3. Flexible Length & Compact Design for Versatile Installation
With a 4.0-meter (13.1-foot) length (optimized for industrial reach) and compact 1.5x1.3x113cm dimensions, the cable adapts to tight routing spaces (such as turbine casings, pump housings, and confined control cabinets). The lightweight 0.14kg design eases handling during installation, while compatibility with 0.2 to 1.5 mm² (16 to 24AWG) field wiring simplifies integration with standard industrial wiring systems—reducing installation time and labor costs.
