CI522 3BSE012790R1 S500 Interface module, China CI522 3BSE012790R1 S500 Interface module Manufacturers, Suppliers, Factory

Overview

Place of Origin:	Sweden
Brand Name:	ABB
Model Number:	CI522 3BSE012790R1
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Parameter	Value
Module	S500 Interface Module
Communication	Modbus TCP server
Digital Inputs	8 DI, 24 V DC
Digital Outputs	8 DO, 24 V DC, 0.5 A
Configurable I/O	8 DI/DO, 24 V DC, 0.5 A (CI522-MODTCP)
Expandability	Up to 10 I/O modules
Product Weight	0.133 kg
Length	62 mm
Height	76 mm
Width	67.5 mm
Industrial Ethernet	0
Other Interfaces	0
Parallel	0
RS-232	0
RS-422	0
RS-485	0
Serial TTY	0
USB	0
Wireless	0
Analog Inputs	0
Analog Outputs	0
Number of Digital Inputs	8
Number of Digital Outputs	8
Number of Configurable Digital I/O	8
Input Voltage Type	DC
Input Voltage (Uin)	24 V DC
Input Current	5 mA
Delay Time (τ)	0.1 to 32 ms
Output Type	Transistor
Output Voltage Type	DC
Output Current	0.5 A
Maximum Output Voltage	20.4 to 28.8 V
Protection Level	IP20
Supply Voltage	20.4 to 28.8 V DC
Electronic Class	27-24-26-07
ETIM 8	EC001604 - Fieldbus, decentralized periphery communication module
ETIM 9	EC001604 - Fieldbus, decentralized periphery communication module
ETIM 10	EC001604 - Fieldbus, decentralized periphery communication module
UNSPSC	32151705
WEEE Type	Business-to-business
WEEE Category	5 Small equipment (no external dimensions > 50 cm)

Description

The ABB CI522 3BSE012790R1 AF100 INTERFACE is a high-performance communication module designed for seamless integration into industrial automation systems. It facilitates efficient data exchange, ensuring optimal system performance and reliability. Supporting multiple industry-standard protocols, it ensures seamless interoperability with a wide range of automation components, simplifying integration efforts and enhancing system flexibility.

Applications

Steel mills (for drive control of rolling mills and continuous casting machines)

Paper mills (for paper machine drives and coating machine systems)

Chemical plants (for automated production lines and material handling control)

Power plants (for frequency converter control of auxiliary equipment)

Cement plants (for fans, pumps, and rotary kiln drive systems)

Competitive Advantage

PROFIBUS-DP Connectivity: Enables reliable data transfer between the controller and field devices using the PROFIBUS-DP protocol.

High-Speed Data Transmission: Supports fast data rates to ensure real-time communication within the network.

Robust Design: Built to withstand harsh industrial environments, ensuring durability and long-term performance.

Easy Integration: Simplifies system integration with plug-and-play functionality, reducing setup time and complexity.

Diagnostics and Monitoring: Provides comprehensive diagnostic capabilities to monitor network health and quickly identify issues.

Compact Form Factor: Space-saving design allows for efficient use of cabinet space without compromising on functionality.

FAQ

Q: What are the differences between CI522 3BSE012790R1 and CI520V1 3BSE012869R1?
A: Both use the AF100 interface, but CI522 3BSE012790R1 is typically designed for connecting drives and S800 I/O, making it an interface module for specific peripherals.

Q: How many frequency converters can one CI522 3BSE012790R1 module support?
A: A single module can connect up to 24 ABB drive units.

Q: Does the CI522 3BSE012790R1 support remote reset?
A: Yes, it can be used to directly reset connected drive units via the AF100 bus.

Q: What is the current status of the CI522 3BSE012790R1 module?
A: This model is gradually entering the later stages of its lifecycle (discontinuation/maintenance phase). Users are advised to stock up on spare parts or consider subsequent models such as CI522A.

Q: How do I set the bus address of the CI522 3BSE012790R1?
A: Usually, its node ID in the AF100 network is set via the module's built-in hardware DIP switch or a specific configuration tool.
