Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
8440-1800 EASYGEN-320 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
8440-1800 EASYGEN-320 |
|
Product Name |
Genset Controller |
|
Dimensions |
15.8 × 15.8 × 4.0 cm |
|
Weight |
0.38 kg |
|
Operating Voltage |
230 VAC |
|
Random Vibration |
10 Hz to 500 Hz |
|
Accuracy |
Class 1 |
|
Operating Temperature |
-40°C to +70°C |
|
Max Exciter Current: 12 Vdc |
11 Adc |
|
Power Factor Correction |
0.95 leading to 0.95 lagging |
|
Communication Interface |
RS485 / Ethernet |
|
Shock |
40 G peak, 11 ms |
|
Humidity |
95%, non-condensing |
Description
Manufactured by Woodward, the easYgen-320 8440-1800 is a Genset controller released by the company in their easYgen-300 series. This series is designed to offer generator and engine protection, generator set controls, and engine crank sequencing along with generator voltage measurement.
Applications
Mobile Emergency Power Vehicle Plants: All-weather outdoor operation with automatic generator control in harsh conditions.
Data Center Power Systems: High-precision automatic synchronization for fast backup power switching.
Marine Engine Manufacturing Plants: Improves generator stability under complex reactive loads.
Wind and Solar Hybrid Plants: Central microgrid controller with SCADA data communication.
High-Altitude Mining Systems: Enables reliable operation in extreme cold unattended control cabinets.
Special note
Before performing maintenance, discharge static electricity by touching grounded metal objects such as pipes or metal cabinets. Keep vinyl, Styrofoam, and plastic materials away from the control to prevent static buildup.
When connecting a magnetic pickup with shielded wiring, connect the shield to a ground terminal only; do not ground the shield at the magnetic pickup end. The magnetic pickup input frequency must be limited to 14 kHz.
FAQ
Q: What is the operating voltage of 8440-1800 EASYGEN-320?
A: The rated operating voltage is 230 VAC.
Q: What is the random vibration frequency range of 8440-1800 EASYGEN-320?
A: The random vibration frequency range is 10 Hz to 500 Hz.
Q: What is the measurement accuracy of 8440-1800 EASYGEN-320?
A: The measurement accuracy is Class 1.
Q: What is the operating temperature range of 8440-1800 EASYGEN-320?
A: The permissible operating temperature range is -40°C to +70°C.
Q: What is the maximum excitation current of 8440-1800 EASYGEN-320 at 12 Vdc?
A: The maximum excitation current can reach 11 Adc.
