Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5463-473 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5463-473 |
|
Product Type |
SIO CPU Controller Module |
|
Dimensions |
16 × 16 × 12 cm |
|
Weight |
0.91 kg |
|
Firmware / OS |
Ver 4.4 OPSYS |
|
On-Board Toggle Switch |
Yes |
|
Connector Type |
Male pin header |
|
Power Supply |
Typically 24 VDC |
|
Operating Temperature |
-40°C to +85°C |
|
Storage Temperature |
-40°C to +100°C |
Description
5463-473 is an SlO CPU Controller Module manufactured and designed by Woodward and used in Gas Turbine Control Systems. A CPU Controller Module is a component that manages and controls the operations of a central processing unit (CPU) in a computer system.The CPU controller is responsible for coordinating various functions within the CPU. such as instruction fetching, decoding, execution, and memory access.
Applications
Thermal power plants: Used as the core CPU in turbine digital electro-hydraulic control systems for speed protection and fuel control logic.
Heavy chemical plants: Used in compressor governor racks with 24V DC supply for stable operation in redundant power systems.
Shipbuilding yards: Used in marine propulsion and power automation systems, designed for harsh engine room environments.
Natural gas stations: Used in pipeline compressor control cabinets, ensuring reliable operation under high ambient heat conditions.
Specific tasks
Instruction fetching: The CPU controller retrieves instructions from the memory or cache and prepares them for execution.
Instruction decoding: It interprets the fetched instructions and determines the appropriate actions to be taken by the CPU.
Execution control: The CPU controller manages the execution of instructions, ensuring they are executed in the correct order and coordinating with other components like the arithmetic logic unit (ALU) and registers.
Memory management: It controls the interaction between the CPU and memory, including managing the memory hierarchy, caching, and virtual memory operations.
Interrupt handling: The CPU controller handles interrupts generated by external devices or internal events, suspending the current execution and directing the CPU to service the interrupt request.
FAQ
Q: What firmware system version does the 5463-473 run?
A: Runs Ver 4.4 OPSYS firmware system.
Q: Does the 5463-473 include an onboard toggle switch?
A: Equipped with an onboard toggle switch.
Q: What type of connector does the 5463-473 use?
A: Uses male pin header connector type.
Q: What DC power supply is typically required to operate the 5463-473?
A: Typically requires 24 VDC power supply.
Q: What is the storage temperature range of the 5463-473?
A: Storage temperature range is -40°C to +100°C.
