Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51309355-001 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51309355-001 |
|
Product Type |
Processor Board |
|
Dimensions |
2 x 13.5 x 24 cm |
|
Weight |
0.1 kg |
|
Supported Inputs |
Up to 4 analog variables (RTD, thermocouples, current loops) |
|
Recording Type |
Circular chart; fiber-tip pens |
|
Display |
Digital display of process values |
|
Control Outputs |
1–2 digital control loops supported |
|
Mounting Type |
PCB assembly for DR4500 chart recorder |
|
Input Impedance (4–20 mA Mode) |
250 Ω |
|
Input Impedance (0–10 V Mode) |
200 kΩ |
|
Sampling Rate (1–2 Inputs) |
3 samples per second |
|
Sampling Rate (3–4 Inputs) |
3 samples every 2 seconds |
|
Digital Display Driver |
6-digit process variable display + 8-digit configuration guidance (English characters) |
Description
The 51309355-001 is a processor board used in the Honeywell DR4500 circular chart recorder series. It digitally records up to four process variables while displaying real-time values and generating precise analog pen traces via fiber-tip pens.
Applications
Petrochemical Plants: Run refinery control logic and safety interlocks.
Power Plants: Coordinate boiler and turbine real-time control.
Steel Plants: Manage blast furnace and casting process control.
Fine Chemical Plants: Handle reactor multi-loop control calculations.
Pharmaceutical Plants: Execute batch process control operations.
Key Features
Multiple Process Variable Recording: Logs up to four variables simultaneously on the same timeline.
Hybrid Analog/Digital Output: Combines analog fiber-tip pen traces with precise digital readings.
Digital Display: Shows current process variable values in engineering units.
Configurable Input Ranges: Compatible with various sensors and transmitters.
FAQ
Q: What is the maximum number of analog variable inputs supported by 51309355-001?
A: It supports up to 4 analog variable inputs.
Q: What type of chart is used by 51309355-001 for recording?
A: It uses a circular chart for recording.
Q: What is the sampling rate of 51309355-001 when 3 to 4 inputs are connected?
A: It is 3 samples every 2 seconds.Q: How many digital control loops does 51309355-001 support?
A: It supports 1 to 2 digital control loops.
Q: What is the input impedance of 51309355-001 in 0–10 V mode?
A: It is 200 kΩ in 0–10 V mode.
