Overview
330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes
At a Glance
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-10-05-02-05 |
Minimum Order Quantity: |
1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Product Overview
Description
The 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes are high-precision eddy current sensors engineered by Bently Nevada, a global pioneer in industrial machinery condition monitoring and protection solutions. As a core model of the 3300 XL 8 mm Proximity Probes product line, this sensor is specifically designed to deliver reliable static position tracking and dynamic vibration measurement for critical rotating equipment, converting electromagnetic field variations between the probe tip and conductive targets into a linear voltage output that is directly proportional to the gap distance. Manufactured in the USA with original factory-sealed packaging, the 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes adhere to the stringent quality standards of Bently Nevada, ensuring consistent performance, long-term durability, and seamless integration into both new and legacy industrial monitoring systems.
Equipped with CSA, ATEX, and IECEx certifications, the 3300 XL 8 mm Proximity Probes are qualified for safe deployment in explosive environments, making them a trusted choice for high-risk sectors such as oil and gas, petrochemical processing, and power generation. Mechanically, the 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes feature a 0 mm unthreaded length and 100 mm overall case length, paired with a 0.5-meter (1.6 feet) standard cable terminated by a miniature coaxial ClickLoc connector—this compact design ensures flexible installation in space-constrained mounting scenarios, including narrow bearing housings, small centrifugal compressors, and high-speed pump assemblies. With slim dimensions of 1.7x1.4x60 cm and an ultra-lightweight build of 0.08 kg, the 3300 XL 8 mm Proximity Probes eliminate the need for costly structural modifications while maintaining exceptional measurement stability.
Key Functions
Applications
The 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes are ideally suited for vibration and position monitoring in explosive environments such as oil refineries, petrochemical plants, and gas compression stations. With CSA, ATEX, and IECEx certifications, these probes can safely operate in hazardous areas where flammable gases or vapors are present, providing accurate real-time data on shaft dynamics to prevent catastrophic equipment failures and ensure compliance with global safety standards.
This 3300 XL 8 mm Proximity Probe model is a perfect fit for space-constrained rotating machinery including small centrifugal compressors, high-speed pumps, and compact turbine generators. Its 0 mm unthreaded length, 100 mm overall case length, and lightweight 0.08 kg design allow seamless installation in narrow bearing housings and confined internal machine structures, while the 0.5-meter cable and ClickLoc connector provide flexible wiring options without compromising signal integrity.
The 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes serve as a cost-effective retrofit solution for legacy 3300 series monitoring systems in power generation and heavy manufacturing facilities. Its backward compatibility with non-XL 3300 series 5 mm/8 mm probes enables facilities to upgrade their condition monitoring capabilities without full system overhauls, supporting Keyphasor reference signal generation and speed quantification to enhance predictive maintenance efficiency.
Official Specifications
Quick Detail
|
Agency Approval Option: |
CSA, ATEX, IECEx Approvals |
|
Unthreaded Length Option : |
0 mm |
|
Overall Case Length Option : |
100 mm |
|
Total Length Option: |
0.5 meter (1.6 feet) |
|
Connector and Cable-Type Option: |
Miniature coaxial ClickLoc connector, standard cable |
|
Dimension: |
1.7x1.4x60cm |
|
Weight: |
0.08kg |
Specifications
|
Operating Temperature Range: |
-50°C to +165°C (-55°F to+340°F) |
|
Linear Range: |
2 mm (80 mils) |
|
Output Resistance: |
45 Ω |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Power: |
Requires -17.7Vdc to -25 Vdc |
|
Probe Tip Material: |
Polyphenylene sulfide (PPS) |
|
Probe Case Material: |
AISI 303 or 304 stainless steel(SST) |
Frequently Asked Questions
What is the model number?
The listed model number is 330103-00-10-05-02-05.
What is the brand name?
The listed brand name is Bently Nevada.
What is the place of origin?
The listed place of origin is USA.
What are the packaging details?
The listed packaging details are Original new Factory Sealed.
What is the delivery time?
The listed delivery time is 5-7 days.
Is this model available?
The listed supply status is In stock.
What are the payment terms?
The listed payment terms are T/T.
Compatibility & Ordering Notes
Competitive Advantage
1.Global Hazardous Area Certification for Versatile Deployment
The 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes hold CSA, ATEX, and IECEx certifications, which is a key competitive edge over non-certified alternatives. These approvals allow direct deployment in explosive environments across global markets, eliminating the need for additional protective enclosures or custom modifications, simplifying compliance with international safety standards, and reducing both installation time and long-term operational costs.
2.Compact & Lightweight Design for Space-Constrained Installations
Featuring a 0 mm unthreaded length, 100 mm overall case length, and 0.08 kg lightweight build, the 3300 XL 8 mm Proximity Probes solve the installation challenges posed by bulkier sensors in narrow bearing housings and compact rotating machinery. This space-optimized design eliminates the need for costly structural modifications, while the miniature coaxial ClickLoc connector ensures a secure, vibration-resistant connection that prevents signal interruption in high-vibration operating conditions.
3.API 670 Compliance & Rugged Material Construction for Long-Term Durability
Fully compliant with the strict API 670 Standard, the 330103-00-10-05-02-05 3300 XL 8 mm Proximity Probes meet the highest industry requirements for performance and reliability. Constructed with a PPS probe tip and AISI 303/304 SST case, the probe delivers superior resistance to chemical erosion, dust, and oil contamination, maintaining stable operation across a wide temperature range of -50°C to +165°C. This rugged construction extends the probe’s service life, reduces maintenance frequency, and lowers replacement costs compared to standard sensors.
