Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
UR6CH |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Product Name: |
Digital I/O Module |
|
Model Number: |
UR6CH |
|
Dimensions: |
4 x 18.5 x 17.1 cm |
|
Weight: |
0.9 kg |
|
Input Voltage Range: |
12–48 V DC |
|
Output Voltage: |
5 V DC |
|
Maximum Output Current: |
10 A |
|
Material: |
PC |
|
Operating Temperature: |
-20 to +60 °C |
|
Contact Configuration: |
1 SPDT (1 trip, 1 normally open, 1 normally closed) |
|
Control Power: |
AC 24–250 V or DC 24–250 V |
|
Contact Current Rating: |
6 A AC/DC |
Description
The UR6CH module is a high-performance digital I/O module designed to provide additional digital input and output functions for UR series relays, enabling seamless communication with auxiliary equipment. It is suitable for various industrial automation applications, featuring high-speed data transmission, rich functionality, and a modular design.
Applications
Power plants (monitoring circuit breaker status, operating isolating switches, and synchronous control logic)
Chemical plants (collecting limit switch and pressure switch signals, and controlling field solenoid valves)
Oil refineries (integrating pump set interlock signals and remote operation of emergency shut-off valves)
Steel plants (for logic and timing control of automated rolling lines and material conveying systems)
Cement plants (monitoring belt conveyor operation status and start/stop interlocks of each process section)
Paper mills (coordinating status feedback and operating logic of multi-unit drive systems)
Features
High Reliability: Suitable for industrial environments, offering high reliability.
Good Compatibility: Compatible with various PLCs and controllers.
Easy Installation: Simple installation and easy maintenance.
Modular Design: Facilitates system expansion.
Functions
The UR6CH module is primarily used for data acquisition and signal control. It can acquire various data from field devices, such as temperature, pressure, and flow rate, and control the operating status of field devices, such as motor starting and valve opening/closing. Furthermore, it can connect to Human-Machine Interface (HMI) devices to achieve human-machine interaction.
FAQ
Q: What is the UR6CH?
A: It is a digital I/O module.
Q: How are the UR6CH packaged?
A: Its packaging generally involves multiple layers of protection to ensure safe transit.
Q: How long is the warranty period of UR6CH?
A: We offer a standard one-year warranty for all new and original products.
Q: Do you offer any discounts?
A: Yes! For discounts on UR6CH, please contact John for the best offer.
