Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
TC-PPD011 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
TC-PPD011 |
|
Product Type |
Battery Extension Module |
|
Dimensions |
3.8 × 12.7 × 17.8 cm |
|
Weight |
0.54 kg |
|
Operating Voltage |
24 VAC/DC |
|
Current Draw @ 24V DC |
0.036 A |
|
Current Draw @ 5V DC |
0.112 A |
|
Additional Current Rating |
100 mA |
|
Voltage Rating |
30 VDC |
|
Mounting Type |
Rack mount |
|
Operating Temperature |
-20°C to +60°C |
Description
The TC-PPD011 is a battery extension module from Honeywell, used to ensure reliable backup power for industrial automation systems. This battery extension module supports continuous operation during power fluctuations or outages.
Applications
Power Plants: Provide backup power for core DCS controllers during outages.
Chemical Plants: Maintain reactor control during unexpected power loss.
Refineries: Enable seamless power switching for critical instruments.
Steel Mills: Support uninterrupted power for cooling and safety controllers.
Semiconductor Plants: Protect precision controllers from voltage fluctuations.
Features
Extends system uptime by enhancing battery backup
Lightweight, compact design for simple installation
Stable performance under varying power conditions
Compatible with Honeywell PLC systems
Troubleshooting
“Low Battery Voltage/Backup Fault”: Check 24V AC/DC input stability. If normal, internal storage has reached end-of-life and requires module replacement.
Power loss data loss: Inspect TC-PPD011 slot contacts and backplane pins for oxidation or poor connection affecting 5V DC (0.112 A) backup supply.
Overheating/burnout: Output is limited to 30VDC / 100mA. Do not drive high-power relays or solenoids directly to avoid damage.
FAQ
Q: What is the operating voltage of TC-PPD011?
A: The operating voltage is 24 VAC/DC.
Q: What is the current consumption of TC-PPD011 at 24V DC?
A: The current consumption is 0.036 A.
Q: What mounting method does TC-PPD011 support?
A: It supports rack mounting.
Q: What is the rated voltage of TC-PPD011?
A: The rated voltage is 30 VDC.
Q: What is the operating temperature range of TC-PPD011?
A: The operating temperature range is -20°C to +60°C.
