Overview

Place of Origin:	USA
Brand Name:	ICS TRIPLEX
Model Number:	TC-003-02-2M5
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Parameter	Value
Part Number	TC-003-02-2M5
Part Name	Power Cable (T8293 to Input FTA)
Cable Length	2.5 m
Voltage Rating	250 V
Current Rating	10 A
Wire Gauge	16 AWG
Insulation / Jacket Material	LSZH (low smoke zero halogen) flame-retardant; PVC insulation
Connection Start Point	T8293 15-way fused power distribution module
Connection End Point	Input Field Termination Assembly (FTA)

Description

The TC-003-02-2M5 Trusted Power Cable is designed to provide reliable power connections for industrial applications. It features high-quality materials and construction, ensuring secure and efficient energy transmission in demanding environments.

Applications

Large Petrochemical Plants: Deliver safe power from fused boards to dense I/O modules in hazardous zones.

Combined Cycle Plants: Ensure stable power transfer between main bus and FTA in hot, dusty turbine rooms.

Offshore Oil Production: Provide reliable power in compact SIS cabinets under high salt spray conditions.

Coal Gasification Plants: Support safe cabling in flammable dusty control rooms to reduce short-circuit risks.

Biopharma Plants: Maintain stable power in cleanroom control cabinets with safe materials.

Common Faults and Troubleshooting

Single Input FTA undervoltage or disconnection: Often caused by a blown fuse on the T8293 distribution module or loose long-distance cable terminals. Check fuse status and retighten both cable ends.

Cable sheath wear or scratching: Cabinet routing edges may damage LSZH insulation. Apply heat-shrink tubing; if the 16 AWG core is damaged, replace the cable.

Terminal overheating at crimp points: Long-term operation near 10A limit increases resistance and local heat. Disconnect power and re-crimp both ends using the original tool.

FAQ

Q: What is the length and application of the TC-003-02-2M5 power cable?
A: It is 2.5 m long and connects the T8293 fused power distribution module to the Input FTA.

Q: What materials and wire specification does the TC-003-02-2M5 cable use?
A: It uses 16 AWG copper conductors with PVC insulation and LSZH flame-retardant outer sheath for safety.

Q: What are the insulation voltage rating and continuous current of the TC-003-02-2M5 cable?
A: It supports 250 V insulation rating and 10 A continuous current.

Q: Can the TC-003-02-2M5 cable be used at 12 A load?
A: No, it is limited to 10 A; 12 A overload may cause overheating and insulation failure.

Q: What maintenance rules apply when using the TC-003-02-2M5 with T8293 modules?
A: Fuse rating must not exceed 10 A so protection acts before cable damage occurs.
