Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
TC-001-02-1M5 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
TC-001-02-1M5 |
|
Part Name |
Chassis Power Cable (MCB Distribution Unit to Controller / First Expander Chassis) |
|
Cable Length |
1.5 m |
|
Rated Voltage |
24 Vdc |
|
Maximum Current |
20 A |
|
Insulation / Jacket Material |
Low smoke zero halogen (LSZH) or industrial flame-retardant PVC |
|
Operating Temperature |
0°C to +60°C |
|
Typical Start Point |
T8292 Intelligent Power Distribution Unit (MCB output) |
|
Typical End Point |
T8100 Controller chassis or first T8300 expander chassis |
Description
The TC-001-02-1M5 Chassis Power Cable is a heavy-duty industrial power connection designed to deliver stable and reliable DC power within high-integrity automation and control systems. It is engineered to ensure safe and efficient power transmission between power distribution units and main or expansion controller chassis in demanding industrial environments.
Applications
Oil & Gas Refineries: Delivers safe power to control systems in hazardous zones.
Offshore Platforms: Provides reliable power for compact control cabinets.
Thermal Power Plants: Ensures stable power between breaker and control units.
Fertilizer Plants: Maintains stable power in corrosive environments.
Semiconductor Plants: Uses low-smoke cables for safe cleanroom operation.
Competitive Advantage
High flexibility: The cable supports FPGA-based programming, allowing customized logic for different automation and control systems, suitable for both new and existing upgrades.
High performance: It delivers fast and accurate data processing to meet high-speed control and custom task requirements.
Easy integration: It integrates with PLC I/O, sensors, and drives, and supports industrial protocols like PROFIBUS for efficient communication and data exchange.
FAQ
Q: What is the length and typical connection use of the TC-001-02-1M5 chassis power cable?
A: It is 1.5 m long and connects a T8292 power distribution unit to T8100 main or T8300 expansion chassis.
Q: What does “02” represent in the TC-001-02-1M5 cable designation?
A: It indicates LSZH or flame-retardant industrial PVC insulation for high safety performance.
Q: What are the rated voltage and maximum current of the TC-001-02-1M5 cable?
A: It supports 24 Vdc systems with a maximum current of 20 A.
Q: What is the operating temperature range of the TC-001-02-1M5 cable?
A: It operates safely from 0°C to +60°C.
Q: Can the TC-001-02-1M5 cable be used at 25 A load?
A: No, it is limited to 20 A; 25 A overload risks overheating and insulation damage.
