Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T9801 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
T9801 |
|
Product Type |
Digital Input Termination Assembly |
|
Dimensions |
13 x 4 x 4.5 cm |
|
Weight |
0.1 kg |
|
Channels |
16 Channel Simplex |
|
Input Voltage |
24 VDC (18–32 VDC rated range) |
|
Isolation |
Non-isolated |
|
Real-Time Response |
0.924 ms / 1.676 ms / 2.453 ms |
|
Safety Certification |
Class I, Division 2 (Groups A, B, C, D) |
|
Pollution Degree |
2 |
|
Installation Type |
Digital Input Termination Assembly (FTA) |
Description
The T9801 Digital Input Termination Assembly is a digital input termination assembly used to terminate signals on a digital input signal line. This component is usually composed of resistors, capacitors, diodes and other components to prevent signal reflection and interference, as well as to ensure the stable transmission of digital signals. The digital input terminator is usually installed on the digital input terminal to enable connection to the signal line.
Applications
Oil & Gas Pipeline Distribution Stations: Local collection of valve and contact signals in field control cabinets.
Industrial Machinery Manufacturing Plants: Distributed integration of proximity and limit switch signals in automation lines.
Smart Water & Wastewater Plants: Centralized wiring of relay dry-contact signals in remote control panels.
Food & Pharma Packaging Plants: High-speed transmission of conveyor and detection contact signals.
Non-Ferrous Metallurgy Rolling Plants: Standard digital I/O interconnection for auxiliary process systems.
Troubleshooting
FAQ
Q: How many digital input channels can T9801 support?
A: Up to 16-channel high-density digital input connections.
Q: What DC voltage range can T9801 tolerate under unstable power conditions?
A: 18–32 Vdc wide operating range from 24 Vdc nominal supply.
Q: What system scan times does T9801 support?
A: Supports 0.924 ms, 1.676 ms, and 2.453 ms scan cycles.
Q: What hazardous area certification does T9801 have?
A: Suitable for Class I, Division 2, Groups A–D environments.
Q: Why must T9801 non-isolated design be considered in system planning?
A: Requires shared reference potential and clean Pollution Degree 2 wiring conditions.
