Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T9030 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
T9030 |
|
Product Type |
OPC Portal Server |
|
Software Build |
1.20.508 (typical; aligned with AADvance 2.11 releases) |
|
Upstream Interface |
OPC DA 1.0a / 2.05a |
|
Data Refresh Rate |
Configurable; minimum 100 ms |
|
Safety Integrity Level |
SIL 3 |
|
SOE Support |
1 ms SOE data forwarding from DOTA/DITA termination assemblies |
|
Safety Standards |
IEC 61508 / IEC 61511 compliant |
|
System Function |
OPC data gateway / portal server |
Description
The T9030 is an OPC portal server manufactured under the ICS Triplex AADvance / Trusted series by Rockwell Automation. This server is used to securely export high-speed real-time data from core safety controllers to third-party distributed control systems (DCS), human-machine interfaces (HMI), and plant-wide supervisory networks.
Applications
Automotive Plants: Integrates shop-floor data into factory management systems.
Chemical Plants: Sends instrument data to central control room displays.
Steel Plants: Collects blast furnace and rolling line data for monitoring.
Power Plants: Centralizes boiler, turbine, and auxiliary equipment data.
Troubleshooting
OPC communication interrupted: Check network between T9030 and controller; verify DCOM and port settings in OPC Client.
Slow upper-layer updates (>100 ms): Adjust polling cycle, reduce subscribed points, and check network bandwidth or switch congestion.
Missing SOE 1 ms timestamps: Verify clock sync, enable SOE cache queue, and check for database write bottlenecks.
FAQ
Q: What is the main Build version of the T9030 OPC portal server?
A: Build 1.20.508, typically released with AADvance 2.11 systems.
Q: What upstream communication interfaces does the T9030 support?
A: OPC DA 1.0a and OPC DA 2.05a industrial standards.
Q: What is the maximum data refresh rate of the T9030?
A: Down to 100 ms configurable polling and publishing cycle.
Q: What safety compliance level does the T9030 meet?
A: IEC 61508 / IEC 61511 compliant, supporting SIL 3 systems.
Q: Does the T9030 support high-precision SOE timestamp forwarding?
A: Yes, it transmits 1 ms SOE event data to upper-layer databases.
