Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T8270 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
T8270 |
|
Part Name |
Fan Assembly Rack |
|
Dimensions |
48.1 × 28 × 8.8 cm |
|
Weight |
1.86 kg |
|
Voltage Range |
18 to 28 Vdc |
|
Fans |
4 × Papst Type 8414NG |
|
Fan MTBF (40°C) |
70,000 hours |
|
Fan MTBF (70°C) |
35,000 hours |
|
Fusing |
Internal 250 mA anti-surge |
|
Power Consumption |
2 × 4 W |
|
Air Flow (at 3100 rpm) |
69 m³/h (40.6 ft³/min) |
|
Operating Temperature |
0°C to +60°C (+32°F to +140°F) |
|
Non-operating Temperature |
-20°C to +70°C (-4°F to +158°F) |
|
Relative Humidity |
10–95% RH (non-condensing) |
Description
T8270 is an industrial-grade Fan Assembly Rack designed for high-reliability control cabinet cooling in safety-critical automation systems. It provides forced air cooling and optimized airflow management to ensure stable thermal conditions for control electronics and high-density I/O modules.
Applications
Petrochemical Refineries: Cools high-density I/O modules in ESD cabinets under full load.
Thermal Power Plants: Maintains airflow in FSSS and turbine protection cabinets.
Automotive Manufacturing: Provides reliable cooling to prevent control cabinet overheating.
Steel Plants: Keeps controllers stable in high-temperature environments.
Coal Gasification Plants: Dissipates heat in safety instrument cabinets for stable operation.
Features
FAQ
Q: What fan brand is used in T8270, and how long can it run at 40°C?
A: It uses 4 ebm-papst 8414NG fans, with MTBF up to 70,000 hours (~8 years).
Q: Can T8270 operate if supply voltage drops to 20 VDC?
A: Yes. It supports 18–28 VDC wide-range operation.
Q: At what speed is the 69 m³/h airflow rating measured in T8270?
A: At a rated speed of 3100 rpm.
Q: Will high temperature reduce T8270 fan life in steel plants?
A: Yes. At extreme heat, MTBF drops from 70,000 to about 35,000 hours.
Q: Will a jammed fan in T8270 cause system short circuit?
A: No. Built-in 250 mA anti-surge fuse isolates the faulty branch.
