330130-045-00-05 3300 XL Standard Extension Cable

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	330130-045-00-05
Minimum Order Quantity:	1
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The 3300 XL Standard Extension Cable (model 330130-045-00-05) represents a significant advancement in eddy current proximity transducer system connectivity. Designed to complement the 3300 XL 8 mm proximity probes, this extension cable ensures optimal signal transmission and system reliability for vibration and position measurements in industrial machinery. Incorporating state-of-the-art design improvements over previous cable models, the 3300 XL extension cable enhances both durability and performance in demanding environments.

A key innovation in this extension cable is the patented TipLoc molding technology, which creates an exceptionally strong bond between the probe tip and probe body. This design improvement reduces the risk of mechanical failure and ensures consistent measurement accuracy during operation. In addition, the cable employs a patented CableLoc system, capable of withstanding a pull strength of up to 330 N (75 lbf), which secures the connection between the probe cable and the probe tip, even under harsh industrial conditions. For applications where fluid ingress could be a concern, the optional FluidLoc cable configuration prevents oil and other liquids from entering the cable interior, protecting both the sensor and the machinery from potential damage.

The 3300 XL Standard Extension Cable maintains the precise performance characteristics of the 3300 XL 8 mm system. The system outputs a voltage directly proportional to the distance between the probe tip and the measured conductive surface, allowing accurate measurements of both static positions and dynamic vibrations. This makes it ideal for fluid-film bearing machines, Keyphasor reference signals, and rotational speed monitoring.

Designed with compliance in mind, the 3300 XL 5-meter standard extension cable fully meets the API 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. Moreover, it supports complete interchangeability with all 3300 XL 8 mm transducer system components, including probes and Proximitor sensors, eliminating the need for component matching or bench calibration. The extension cable is also backward compatible with 3300 series 5 mm and 8 mm transducers, offering flexibility for installations with limited space or where smaller probes are preferred.

In summary, the 3300 XL Standard Extension Cable delivers robust mechanical reliability, precise signal integrity, and seamless system integration. Its innovative design features, including TipLoc, CableLoc, and optional FluidLoc, make it a superior choice for high-precision industrial monitoring applications.

Applications

Vibration and Position Measurement

The 3300 XL Standard Extension Cable is designed to work seamlessly with the 3300 XL 8 mm and 5 mm proximity probes, providing accurate transmission of signals for both static (position) and dynamic (vibration) measurements. When paired with a proximity probe and Proximitor sensor, the system delivers output voltage directly proportional to the distance between the probe tip and the observed conductive surface, enabling precise monitoring of fluid-film bearing machines. This makes it ideal for critical machinery condition monitoring in industrial applications.

High-Reliability Industrial Environments

Constructed with 75 Q triaxial FEP-insulated material, the extension cable is engineered to withstand harsh industrial environments. Optional features such as the patented CableLoc design provide 330 N (75 lbf) pull strength, ensuring a secure and durable connection between the probe tip and cable. For applications exposed to liquids, the optional FluidLoc cable prevents oil or other fluids from leaking through the cable interior, enhancing safety and reliability in lubrication-heavy machinery.

Flexible Installation and Compliance

With a 4.5-meter (14.8 feet) cable length and standard connector options, the extension cable allows flexible routing in high-density installations. It supports field wiring from 16 to 24 AWG (0.2–1.5 mm²), providing adaptability for various plant setups. Moreover, the cable system meets international safety and quality standards, including CSA, ATEX, and IECEx approvals, making it suitable for use in hazardous or explosive environments.

Compatibility and Interchangeability

The 3300 XL Standard Extension Cable is fully compatible and interchangeable with other 3300 XL system components as well as older 3300 series probes and Proximitor sensors. This ensures ease of maintenance and replacement, eliminating the need for individual component bench calibration. Its backward compatibility also allows integration in systems where space constraints require the use of a 5 mm probe instead of an 8 mm probe.

Specifications

Competitive Advantage

Robust and Durable Design

The 3300 XL Standard Extension Cable incorporates a patented TipLoc molding method and CableLoc design, providing a secure bond between the probe tip and cable. With a pull strength of 330 N (75 lbf), it ensures reliable performance even in high-vibration or mechanically demanding environments, reducing downtime and maintenance costs.

Superior Fluid Resistance

Optional FluidLoc cable protection prevents oil, lubricants, or other liquids from entering the cable interior, making it ideal for applications in fluid-film bearing machines and other oil-rich industrial environments. This feature enhances operational safety and prolongs system life.

High-Performance Signal Transmission

Constructed with 75 Q triaxial FEP-insulated material, the cable maintains high signal integrity over its 4.5-meter length, supporting accurate static (position) and dynamic (vibration) measurements. Its linear range of 2 mm (80 mils) ensures precise distance detection, critical for condition monitoring and Keyphasor reference or speed measurements.

International Standards Compliance

The cable carries CSA, ATEX, and IECEx approvals, meeting stringent safety and quality standards for use in hazardous or explosive environments. This certification ensures global applicability and compliance with industrial regulations.

Compatibility and Interchangeability

The 3300 XL Standard Extension Cable is fully backward compatible and interchangeable with other 3300 XL and non-XL 3300 series probes, extension cables, and Proximitor sensors. This reduces the need for component matching or bench calibration, simplifying maintenance and supporting flexible system upgrades.

Flexible Installation

Supporting field wiring from 16 to 24 AWG (0.2–1.5 mm²) and featuring standard connectors, the cable can be easily routed in high-density DIN-rail installations. Its robust design allows secure and reliable connections in a variety of industrial setups.
