Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T8193 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
T8193 |
|
Part Name |
Trusted Shield Module |
|
Slot Width |
3 standard I/O slots (90 mm / ~3.6 in) |
|
Type |
Metal shielding protection panel |
|
Surface Treatment |
Industrial-grade anti-corrosion conformal coating |
|
Housing Material |
High-strength industrial die-cast aluminum / high-grade electroplated steel |
|
Operating Temperature |
-20°C to +60°C (-4°F to +140°F) |
|
Storage / Transport Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Relative Humidity |
5–95% RH (non-condensing) |
|
Torque Rating |
0.5 to 0.6 Nm |
Description
The T8193 is a high-reliability industrial shield module designed for high-integrity control systems. It is used as a protective and filling component for Trusted system chassis, covering unused rack positions to maintain system integrity and electromagnetic stability.
Applications
Petrochemical Refineries: Used in SIS cabinets to resist corrosive toxic gases with protective coating.
Steel Plants: Blocks strong EMI from furnaces, drives, and high-current bus systems.
Cement Plants: Seals unused rack slots to prevent conductive dust contamination.
Offshore Platforms: Protects empty slots from severe salt spray corrosion.
Thermal Power Plants: Maintains stable airflow and temperature in control racks under harsh conditions.
Common Troubleshooting
Hidden Electromagnetic Noise Inside Rack: Check if T8193 mounting screws are loose. Insufficient torque breaks grounding contact and weakens EMI shielding. Retighten using a torque wrench.
Oil, Acid, or Alkali Contamination on Surface: Heavy industrial residue may reduce convection cooling. Clean during maintenance using a non-conductive cleaner and soft dry cloth.
Screw Jamming or Thread Damage During Reinstallation: Misalignment can damage threads in the die-cast aluminum and steel structure. Align panel properly, start screws by hand, then tighten carefully with tools.
FAQ
Q: What is the main function of T8193, and does it contain electronic circuits or pins?
A: Pure physical shielding module with no electronics. It fills and protects 3 unused I/O slots.
Q: In petrochemical H₂S or ammonia environments, will T8193 corrosion protection fail?
A: No. It uses industrial anti-corrosion coating for harsh gases.
Q: Is there a strict torque requirement when installing T8193 on a Trusted rack?
A: Yes. Tighten to 0.5–0.6 Nm with a torque wrench for shielding and grounding.
Q: Can T8193 withstand high humidity from steam leaks?
A: It works in 5%–95% non-condensing humidity; direct water accumulation must be avoided.
Q: Can T8193 be cut to fit a 30 mm slot?
A: No. Its fixed 90 mm (3-slot) structure cannot be modified.
