Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
SPS5713 51199930-100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
SPS5713 51199930-100 |
|
Product Type |
Main Rack Power Transistor Device |
|
Dimensions |
90 × 20 × 6.5 cm |
|
Weight |
2.48 kg |
|
Package Type |
TO-247 |
|
Input Voltage |
100–240 VAC |
|
Input Frequency |
47–63 Hz |
|
Input Current |
10 A |
|
Output Voltage |
24–26 VDC |
|
Output Current |
20 A |
|
Maximum Ambient Temperature |
60°C |
|
Operating Temperature Range |
-40°C to +150°C |
Description
The Honeywell SPS5713 51199930-100 is a high-performance Main Rack Power Transistor Device suitable for industrial automation control, power electronics systems, and a variety of demanding industrial applications. It works directly with the power module, responsible for finely adjusting, shunting, and regulating the coarse input current.
Applications
Semiconductor Fabs: Low-noise DC output provides stable power for lithography and deposition equipment control systems.
Biopharmaceutical Plants: Wide AC input ensures continuous power for vaccine and blood product production lines.
Automotive Assembly Plants: High-current output supports welding robots and PLC control systems under rapid load changes.
Rail Transit Equipment Plants: Rugged TO-247 package and heatsink design withstand long-term vibration in traction and onboard control systems.
Troubleshooting
24–26 Vdc output power off: Check if AC input exceeds 100–240 Vac or if 10A input protection failed. If AC is normal, disconnect load and inspect for short circuit caused by surge.
Rapid temperature rise near 150°C: Usually caused by overload above 20A. If current is normal, check thermal grease and heatsink screw tightness.
Output voltage drift (outside 24–26 Vdc): High ambient temperature near 60°C may cause thermal drift. Improve cabinet airflow and inspect feedback components.
FAQ
Q: What packaging type does SPS5713 51199930-100 use?
A: It uses a TO-247 package.
Q: What are the input voltage and frequency ranges of SPS5713 51199930-100?
A: Its input voltage range is 100–240 VAC, and its input frequency range is 47–63 Hz.
Q: What is the output voltage of SPS5713 51199930-100?
A: Its output voltage is 24–26 VDC.
Q: What is the output current of SPS5713 51199930-100?
A: This model provides an output current of 20 A.
Q: What is the operating temperature range of SPS5713 51199930-100?
A: Its operating temperature range is -40°C to +150°C.
