6SL3100-1CE14-0AA0 SINAMICS 600 V DC 4000 µF Capacitor Module
The Siemens SINAMICS capacitor module is rated for a 600 V DC input and provides 4000 µF of DC-link capacitance for the matched drive configuration.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6SL3100-1CE14-0AA0 |
| Product Type | DC-link capacitor module |
| Core Function | Adds 4000 µF of capacitance to a 600 V DC SINAMICS DC link |
| Application or Compatible Series | SINAMICS drive systems requiring the specified capacitor-module rating |
Exact Identification
Match 6SL3100-1CE14-0AA0 character by character and confirm the complete SINAMICS 600 V DC 4000 µF Capacitor Module designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The Siemens SINAMICS capacitor module is rated for a 600 V DC input and provides 4000 µF of DC-link capacitance for the matched drive configuration.
The module is identified for a 600 V DC input in the matched SINAMICS drive system. Its 4000 µF capacitance supports the configured DC-link energy requirement. Mechanical arrangement, DC-link connection and discharge safety must match the engineered drive lineup.
Key Functions
Defined DC-Link Rating
The module is identified for a 600 V DC input in the matched SINAMICS drive system.
Additional Energy Storage
Its 4000 µF capacitance supports the configured DC-link energy requirement.
System-Specific Installation
Mechanical arrangement, DC-link connection and discharge safety must match the engineered drive lineup.
Official Specifications
| Cooling Method | Internal air cooling |
|---|---|
| 24 V DC Busbar Current Capacity | 20 A |
| DC-Link Busbar Current Capacity | 100 A |
| DC-Link Connections | 2 connections via integrated DC-link busbars |
| Protective-Earth Connections | 2 |
| Protective-Earth Terminal | M5 screw |
| Module Width | 100 mm |
| Module Height | 380 mm |
| Depth with Supplied Spacer | 270 mm |
| Approximate Weight | 7.2 kg |
| Certificate of Suitability | cULus |
| Operating Principle | Autonomous operation |
| Parallel Operation | Multiple capacitor modules can be operated in parallel |
| Supplied Spacer | Included |
Frequently Asked Questions
What DC-link voltage must match 6SL3100-1CE14-0AA0?
Use the module only with the specified 600 V DC link.
How much capacitance does 6SL3100-1CE14-0AA0 add?
The module provides 4000 µF of capacitance.
Can 6SL3100-1CE14-0AA0 be fitted to any converter cabinet?
No; the mechanical and electrical configuration must match the engineered SINAMICS system.
What must be isolated before replacing 6SL3100-1CE14-0AA0?
Isolate every power source, wait for the DC link to discharge and prove zero voltage.
What should I record before removing 6SL3100-1CE14-0AA0?
Record the installation position, busbar arrangement, grounding, connectors and adjacent modules.
How should 6SL3100-1CE14-0AA0 be handled during installation?
Use the approved lifting and electrostatic precautions and protect all terminals from contamination.
What should be checked after installing 6SL3100-1CE14-0AA0?
Verify fastening, grounding, DC-link polarity, clearances, covers and the approved drive startup sequence.
Compatibility & Ordering Notes
Compatibility Checklist
- Match the capacitor rating and DC-link voltage exactly.
- Use only the approved SINAMICS mechanical and electrical arrangement.
- Prove the DC link is discharged before any service work.
