Siemens SIMATIC PCS 7 Fail-Safe Relay Output MTA 6ES7650-1AM30-6XX0
Manufacturer: Siemens
Condition: Brand New
Lead Time: In Stock
Origin: Germany
Warranty: 12 Months
Email: [email protected]
whatsApp: +86-18150117685
- Overview
- Product Overview
- Key Functions
- Official Specifications
- Frequently Asked Questions
- Compatibility & Ordering Notes
- Hot Selling Models
- Recommended Products
Overview
Siemens · SIMATIC PCS 7 MTA / ET 200M
6ES7650-1AM30-6XX0 SIMATIC PCS 7 Fail-Safe Relay Output MTA
This marshalled termination assembly provides ten fail-safe relay output channels for connecting field loads to the specified ET 200M SM 326 fail-safe output module.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6ES7650-1AM30-6XX0 |
| Product Type | Ten-channel fail-safe relay-output marshalled termination assembly |
| Core Function | Marshals ten fail-safe relay output channels between field wiring and an ET 200M F-output module |
| Application or Compatible Series | SIMATIC PCS 7 and ET 200M safety applications using SM 326 F-DO 10 × 24 V DC / 2 A |
Exact Identification
Match 6ES7650-1AM30-6XX0 character by character and confirm the complete SIMATIC PCS 7 Fail-Safe Relay Output MTA designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
This marshalled termination assembly provides ten fail-safe relay output channels for connecting field loads to the specified ET 200M SM 326 fail-safe output module.
One assembly marshals ten safety-related output circuits. The unit is assigned to the documented SM 326 F-DO module and prefabricated cables. The relay MTA is covered by Siemens functional-safety certification for the approved architecture.
Key Functions
Ten Relay Channels
One assembly marshals ten safety-related output circuits.
ET 200M Pairing
The unit is assigned to the documented SM 326 F-DO module and prefabricated cables.
Safety Certification
The relay MTA is covered by Siemens functional-safety certification for the approved architecture.
Official Specifications
| Assembly Type | Fail-safe relay-output MTA |
|---|---|
| Relay Channels | 10 |
| DC Switching Range | 24 to 150 V DC |
| AC Switching Range | 120 to 230 V AC |
| Maximum Load Current | 5 A |
| Assigned F-Module | 6ES7326-2BF01-0AB0 |
| 3 m Connection Cable | 6ES7922-3BD00-0AS0 |
| 8 m Connection Cable | 6ES7922-3BJ00-0AS0 |
| Functional Safety | IEC 61508, SIL 2 for relay MTA |
| Safety Wiring | Normally open contacts for safety-related use |
| Hazardous-Area Use | Class I Division 2 / Zone 2 under specified conditions |
| Ambient Temperature Range | -25 to +60 °C with documented restrictions |
| System Platform | SIMATIC PCS 7 / ET 200M |
| Module Role | Field marshalling and relay isolation |
Frequently Asked Questions
Which I/O module is paired with 6ES7650-1AM30-6XX0?
Use the specified SM 326 fail-safe digital-output module and approved interconnection cable.
How many relay circuits are provided by 6ES7650-1AM30-6XX0?
Ten fail-safe relay output channels are available.
Which contact arrangement is permitted for safety use with 6ES7650-1AM30-6XX0?
Use the normally open contacts in the validated safety-related installation.
Can 6ES7650-1AM30-6XX0 switch both AC and DC loads?
Yes; keep every circuit within the published AC, DC and current ratings.
Which cable lengths are supported by 6ES7650-1AM30-6XX0?
The approved prefabricated connection options are available in three-metre and eight-metre versions.
What should be recorded before replacing 6ES7650-1AM30-6XX0?
Document every channel, load voltage, cable number, terminal assignment and safety-loop function.
What must be completed after installing 6ES7650-1AM30-6XX0?
Test channel wiring, relay operation, diagnostics and the authorized safety acceptance procedure.
Compatibility & Ordering Notes
Compatibility Checklist
- Use the specified ET 200M fail-safe output module and approved prefabricated cable.
- Keep all field loads within the published AC, DC and current ratings.
- Complete documented safety-loop testing after replacement.
