Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
SD822 3BSC610038R1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
SD822 3BSC610038R1 |
|
Product Type |
Power Supply Module (AC-DC) |
|
Dimensions (H x L x W) |
8 x 14 x 15 cm |
|
Weight |
0.5 kg |
|
Input Voltage Type |
AC |
|
Input Voltage |
230 V |
|
Input Current (max) |
15 A |
|
Number of Outputs |
1 |
|
Output Voltage |
24 V |
|
Output Current (max) |
5 A |
|
Mounting Type |
DIN rail |
Description
The ABB SD822 3BSC610038R1 is a high-efficiency power supply module designed for S800 I/O systems and AC 800M controllers, featuring wide-range AC/DC input and DIN-rail mounting. It provides reliable power for process control systems in harsh environments, featuring high EMC immunity and an optimized, compact design.
Applications
Oil refineries: Provide redundant power for safety instrumented systems within the central control cabinet.
Coal power plants: Ensure stable power supply to desulfurization and denitrification control units in high-temperature environments.
Metallurgical processing plants: Maintain signal accuracy in converter control areas with strong electromagnetic interference.
Pharmaceutical manufacturing plants: Drive highly sensitive environmental monitoring sensors and data acquisition modules.
Wastewater treatment plants: Support remote I/O communication links for distributed pumping stations.
Features
Stable Power Output: Ensures consistent 24V DC supply for automation modules
Dual Protocol Support: Some variants support PROFINET IO RT and PROFIBUS DP V1
Redundant Inputs: Supports dual 24V DC inputs for fault-tolerant operation
Hot-Swap Capability: Enables module replacement without system shutdown
Advanced Diagnostics: LED indicators and remote monitoring via ABB Ability
Extreme Environment Ready: Operates in harsh conditions with ATEX certification
Compact & Rugged Design: Space-saving and built for industrial durability
FAQ
Q: What is the maximum output current supported by the SD822 3BSC610038R1 power supply?
A: The rated maximum output current is 5 A.
Q: On which DIN rails can the SD822 3BSC610038R1 be mounted?
A: It supports standard 35mm DIN rail mounting.
Q: What is the module weight of the SD822 3BSC610038R1?
A: The product weighs approximately 0.5 kg, making installation very convenient.
Q: Must the input voltage of SD822 3BSC610038R1 be 230V?
A: The nominal input is 230V AC, but it typically supports a wide range of AC voltages.
Q: What if a 10A current is required for SD822 3BSC610038R1?
A: Consider using the higher-specification SD823 (10A) model, or parallel connection using redundant modules.
