SBGA-6P1WM 6 POINT GROUP ANNUNCIATOR , China SBGA-6P1WM 6 POINT GROUP ANNUNCIATOR Manufacturers, Suppliers, Factory

Overview

Place of Origin:	U.K.
Brand Name:	Westronics
Model Number:	SBGA-6P1WM
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Dimensions	2x18.5x26.1cm
Weight	0.46 kg
Unit Types	1WM: Mast unit (with common card); 6P: 6 Point alarm
Power Rating	DC 24 V
Power Variation	DC 19–30 V
Accuracy	Less than ±1%
Timer	Flickering range: 1T–3T/sec
Alarm Delay Setting	0–30 sec
Contact Type	"NO" or "NC" (selectable via DIP switch on each alarm card)
Input Signal	Loop current below 10 mA per point
Cable Length	Within 1000 m (≥0.75 mm²)
Visual Lamp Power	2 W max.
Output Contact DC	DC 30 V 1.0 A (resistive)
Output Contact for Buzzer	DC 30 V 0.4 A inductive, p.f=0.4
Switching Capacity	24 V DC: 2 A resistive / 0.8 A inductive, p.f=0.4
AC Switching Capacity	120 V AC: 1 A resistive / 0.4 A inductive, p.f=0.4
Electrical Life Expectancy	10 × 10⁶ cycles
Mechanical Life Expectancy	10,000 × 10⁶ cycles
Secondary Alarm Contact	"NC" dry contact
Insulation Resistance	≥200 MΩ between live part and enclosure
Surge Transient	0.5 kV, 50 µs line/line
Enclosure Material	PC, flame retardant UL94V-0, TRIREX3025G10/G/F reinforced
Insulating Material	PA, UL94V-0
Terminal Block Material	Cu/Zn
Rated Voltage	250 V (UL1059, EN60998)

Description

SBGA series are high quality Annunciators which have visible and audible self-alarm and extenal 2ndary alarm at sensing abnormal signal,and developed so as to be suitable for an alarm system of marine, power plant, steel, chemical plant and any other industrial facilities.And alarm system can be consist of maximumly 600 points by connecting the extension unit (SBGA-P1WEl.Each alarm is separated from the other, and input signal (NO or NCl and 2ndary alarm of each alarm can be individually controlled through the selection at alarm card

Applications

Monitor critical alarms in marine engine control rooms using the SBGA-6P1WM to display six alarm points per unit and trigger audible alerts with a visual lamp rated at 2 W, ensuring each point consumes less than 10 mA loop current.

Control plant-wide alarms in power plants by connecting multiple SBGA-6P1WM units, allowing expansion up to 600 alarm points, while the DC 24V power supply operates within the 19–30V variation to maintain consistent accuracy below ±1%.

Provide automated alarm indication for chemical reactors, where each SBGA-6P1WM input (NO or NC) can be individually set via DIP switches, with alarm delays adjustable from 0–30 seconds to suit process timing.

Use in steel manufacturing facilities to detect equipment malfunctions and activate secondary NC dry contact alarms, capable of handling DC 30V at 1.0A resistive or 0.4A inductive loads.

Integrate into industrial automation systems with SBGA-6P1WM units capable of enduring vibration up to ±0.7G at 30Hz for 2 hours, and temperature ranges from -25°C to +55°C, ensuring reliable operation in harsh environments.

Specifications

External Wire Size (max)	AWG 22–14 (2.5 mm²)
Terminal Block Test Voltage	2.0 kV
Rated Torque	0.5 Nm / M3
Screw Size / Terminal Spacing	5.0 mm
Ambient Operating Temperature	-25 °C to +55 °C
Storage Temperature	-25 °C to +85 °C
Humidity Range	45%–85% RH
Vibration Test	30 Hz for 2 hours (acceleration ±0.7 G)
Total Current Consumption	≤140 mA
Recommended Power Supply with Visual Lamp (2 W)	≥1.0 A

Competitive Advantage

Each SBGA-6P1WM alarm point is electrically isolated, preventing cross-point interference; with electrical life expectancy of 1,000,000 cycles and mechanical life of 10,000,000 cycles, it ensures long-term durability.

DIP switch configurable inputs allow selection between NO and NC contacts without rewiring, making setup faster and reducing downtime in industrial installations.

Secondary alarm outputs of the SBGA-6P1WM can handle DC 30V 0.4A inductive loads, enabling remote monitoring or integration with external buzzer or indicator systems.

The visual lamp consumes only 2 W, and total current consumption remains below 140 mA per unit, allowing efficient power management across multiple units in large-scale systems.

Enclosure materials (PC flame retardant UL94V-0, TRIREX reinforced) and terminal specifications (rated voltage 250V, AWG 22–14 wiring, 0.5Nm torque) make installation secure and compatible with standard industrial wiring practices.
