KC3010X1-BA1 12P6762X062 16-Channel AI Plus HART Module
Official-source product identification, application guidance and ordering checks for KC3010X1-BA1 12P6762X062.
At a Glance
| Brand | Emerson |
|---|---|
| Model | KC3010X1-BA1 12P6762X062 |
| Product Type | 16-Channel AI Plus HART Module |
| Core Function | Acquisition of 4–20 mA HART process-transmitter signals. |
| Application / Compatible Series | DeltaV DCS |
Verified identification
KC3010X1-BA1 12P6762X062 is identified by the complete manufacturer model and the photographed unit.
Application focus
KC3010X1-BA1 12P6762X062 is intended for acquisition of 4–20 mA HART process-transmitter signals.
Ordering control
KC3010X1-BA1 12P6762X062 should be matched by the full nameplate, hardware revision and installed configuration.
Product Overview
KC3010X1-BA1 12P6762X062 is an Emerson DeltaV AI Plus module for sixteen 4–20 mA analog input channels with HART capability.
The DeltaV AI Plus design uses A6 keying and separate local-bus and bussed field-power supplies. Terminal selection must reflect the installed 2-wire, 4-wire, redundant or mass-termination architecture.
Key Functions
Sixteen-Channel Input
Acquires 16 supported 4–20 mA process inputs through the DeltaV traditional I/O architecture.
HART Data Access
Supports HART communication from compatible smart transmitters while preserving the analog process signal.
Flexible Field Termination
Works with the documented A6-keyed 2-wire, 4-wire, redundant and mass-termination AI options.
Official Specifications
| Channels | 16 analog inputs, 4–20 mA HART |
|---|---|
| Local bus | 12 VDC at 150 mA |
| Bussed field power | 24 VDC at 500 mA |
| Field circuit | 24 VDC at 30 mA per channel |
| Terminal key | A6 |
| Sixteen-Channel Input | Acquires 16 supported 4–20 mA process inputs through the DeltaV traditional I/O architecture. |
| HART Data Access | Supports HART communication from compatible smart transmitters while preserving the analog process signal. |
| Flexible Field Termination | Works with the documented A6-keyed 2-wire, 4-wire, redundant and mass-termination AI options. |
| Redundancy Mode | Redundant |
| HART Support | Supported |
| 12 VDC Output Rail | 12 VDC |
| Output Voltage | 24 V DC |
| Output Current Type | DC |
Official source: Emerson DeltaV AI Plus official certificate and M-series Traditional I/O Product Data Sheet. Commercial stock, warranty and shipping statements are seller terms.
