Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
HE693IBS100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
HE693IBS100 |
|
Part name |
Interbus-S Slave Module |
|
Maximum process data words |
64 (32 in / 32 out) |
|
Data width programmable |
Yes (via PLC ladder logic) |
|
PLC base compatibility |
GE Fanuc Series 90-30 internal slot |
|
Maximum communication speed |
Interbus-S network up to 500 kHz |
|
Isolation |
1500 VAC (typical, field-to-logic) |
|
Mounting |
Series 90-30 I/O rack slot |
|
Indicator LEDs |
Error, Run, Network status |
|
Module type |
Slave communication interface |
|
Operating temperature |
0–60°C |
|
Storage temperature |
-40°C to +85°C |
|
Humidity |
5–95% non-condensing |
Description
The HE693IBS100 is a high-performance Interbus-S slave module specifically developed for the GE Fanuc Series 90-30 PLC system. This module serves as a crucial data bridge between the PLC and an external Interbus-S remote bus, enabling efficient bidirectional transmission of process data in the industrial field.
Applications
Steel Smelting Plants: Ensure stable long-distance communication in strong electromagnetic environments.
Food Packaging Plants: Synchronize real-time data across high-speed multi-station lines.
Cement Plants: Support long-term operation in dusty and wide-temperature environments.
Paper Machinery Plants: Act as data bridge for multi-drive tension control systems.
Logistics Sorting Plants: Enable high-speed I/O expansion in automated warehousing systems.
Key Features
Dynamic, programmable Interbus-S data width (the PLC ladder program can manipulate this)
Up to 32 words of Interbus-S process data (32 words in and 32 words out)
PLC controlled module error generation, Host error acknowledge is sent to PLC
Module can be configured to report PLC RUN status to host via I/O and/or module error
FAQ
Q: What is a HE693IBS100?
A: The module is designed for any slot in GE Fanuc Series 90-30 PLC systems and transfers up to 64 words of process data via Interbus-S.
Q: What connectors does the HE693IBS100 have?
A: It includes two 9-pin D connectors labeled IN and OUT for standard Interbus-S communication.
Q: What tools are needed to configure the HE693IBS100?
A: Configuration can be done using a Series 90-30 handheld programmer or GE Fanuc LogicMaster 90-30 software.
Q: What is Interbus-S in the HE693IBS100 system?
A: It is a serial, shift-register-based protocol with a master and slave structure, mainly for process data transfer, not intelligent protocols.
