GJR2393200R1210 Station Bus Coupling Module , China GJR2393200R1210 Station Bus Coupling Module Manufacturers, Suppliers, Factory

Overview

Place of Origin:	Sweden
Brand Name:	ABB
Model Number:	GJR2393200R1210
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Dimensions	1.8x19.7x26.1cm
Weight	0.44 kg
RoHS Status	Not RoHS Compliant
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)
Number of Batteries	0
Bus Interfaces	Standard interface (SS) for station bus, RS485 for remote bus connection, module data interface, monitoring interface, dual-channel station bus coupling (optional)
Module Addressing	Address 60 or 61 for single/dual-channel mode, 62 for setting station, system, and module addresses
Data Transfer	Error-free telegram transfer between 88TK05 and compatible PROCONTROL modules
Diagnostics	Built-in diagnostic and notification functions

Description

ABB's GJR2393200R1210 Station Bus Coupling Module is the heart of communication within a PROCONTROL system. It handles data exchange between various components in a station. It also partners with the 88FT05 module to connect the station bus to a remote bus for wider network communication. This module is used within a Procontrol cabinet as a bus-coupled passive component, requiring no external power supply. It connects to the bus via input and output biaxial cables, connects to workstations using standard coaxial cables, provides grounding to the cabinet enclosure, and is also equipped with a bus termination module.

Features

Function: Manages data flow within a PROcONTROL station and connects to a remote bus.

Applications: Industrial automation systems, process control (specifically PROCONTROL systems).

Installation: Fits in any slot of a PROCONTROL cabinet, with reserved slots in standard cabinets

Compatibility: Works seamlessly with PROCONTROL modules manufactured after 1987 (serial number 9xx8 and above).

No external power supply required: Operates as a passive component in a bus-coupled configuration.

Interface configuration: Equipped with a standard station bus interface, an RS485 remote interface, and a dual channel station bus coupling interface.

Specifications

Supply Voltage	24 V DC ±10%
Current Consumption	≤250 mA typical
Bus Interface	RS-485 differential signaling
Bus Voltage Level	5 V DC logic
Isolation Voltage	≥500 V AC between bus and supply
Mounting	DIN-rail TS35 or panel mount
Enclosure Material	UL94-V0 flame retardant
Operating Temperature	−10 °C to +55 °C
Storage Temperature	−20 °C to +70 °C
Humidity	5–95% RH non-condensing
Data Rate	31.25 kbit/s (standard Profibus)
Supported Protocols	PROFIBUS DP, Modbus (optional)
Node Addressing	DIP switch or software configurable

Competitive Advantage

Support multiple communication protocols
The GJR2393200R1210 supports RS-485, Profibus DP, and optional Modbus, enabling flexible integration with existing PROCONTROL networks.

Provide robust bus isolation
With ≥500 V AC isolation between bus and supply, the ABB GJR2393200R1210 protects sensitive devices from voltage transients and faults.

Enable fast configuration
DIP switch or software-based addressing allows the GJR2393200R1210 to quickly configure node addresses for single or dual-channel operation.

Compact and easy mounting
The ABB GJR2393200R1210 mounts on DIN-rail TS35 or panels, with UL94-V0 flame-retardant housing, supporting industrial installation standards.
