Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
F860-CA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
F860-CA |
|
Product Type: |
Redundant Fieldbus Power Module |
|
Dimensions: |
29.4 × 12 × 5 cm |
|
Weight: |
0.32 kg |
|
Fieldbus Protocol Support: |
FOUNDATION Fieldbus H1 |
|
Number of H1 Segments: |
Up to 8 independent segments |
|
Input Voltage Range: |
19.2–30.0 VDC |
|
Power Module Compatibility: |
Supports F801 or F802 modules (N+1 hot redundancy) |
|
Output Voltage (F801 installed): |
21.5–24.0 VDC per segment |
|
Output Voltage (F802 installed): |
28.0–30.0 VDC per segment |
|
Rated Current (F801 installed): |
0–350 mA per segment |
|
Rated Current (F802 installed): |
0–500 mA per segment |
|
Electrical Isolation: |
Fieldbus to power input: 250 VAC RMS; segment-to-segment: 200 VDC |
|
Termination: |
Integrated automatic terminator per H1 segment |
|
FIM Interface: |
2 × 16-pin connectors (FCAB-0x system cable compatible) |
|
Alarm Output: |
Remote fault alarm contact (NC, 1 A @ 30 VDC) |
|
Protection Rating: |
IP20 |
Description
The F860-CA is a redundant fieldbus power module for Fieldbus H1 fieldbus networks, used to achieve zero downtime through active load sharing between two modules. This module not only features efficient data bus isolation and electrical noise reduction capabilities, but also ensures continuous and stable high-load power output in extreme industrial environments.
Applications
Fine chemical plants: High-level electrical isolation reduces interference and ensures clean digital signal transmission from reactor instruments.
Thermal power plants: Centralized power distribution for desulfurization systems and boiler measurement networks with simplified cabinet wiring.
LNG receiving terminals: Provide safe power and alarm functions for cryogenic and hazardous environments ensuring continuous protection.
Pharmaceutical plants: Stable power delivery for high-precision field instruments enabling accurate batch production control.
Features
Multi-functional control options supporting various input and output channels
User-friendly interface for easy configuration and operation
Rugged construction for durability in harsh industrial environments
Wide operating temperature range for flexible application applications
Modbus RTU communication interface for seamless integration with other systems
FAQ
Q: Which fieldbus protocol is supported by the F860-CA?
A: FOUNDATION Fieldbus H1.
Q: What is the maximum number of independent H1 segments supported by the F860-CA?
A: 8.
Q: What are the alarm output contact ratings of the F860-CA?
A: NC, 1 A @ 30 VDC.
Q: What is the output voltage range per segment when installing the F801 module on the F860-CA?
A: 21.5 to 24.0 VDC.
Q: What is the rated current range per segment when installing the F802 module on the F860-CA?
A: 0 to 500 mA.
