Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
DTPC723A 3EST000210-3450 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Product Model: |
DTPC723A 3EST000210-3450 |
|
Type: |
Interface Module |
|
Dimensions (L×W×H): |
150 x 100 x 50 mm |
|
Weight: |
0.8 kg |
|
Supply Voltage: |
24 V DC |
|
Communication Protocols: |
PROFINET / PROFIBUS (dual support) |
|
I/O Configuration: |
4 DI / 2 DO |
|
Operating Temperature: |
-20°C to +60°C |
|
Protection Rating: |
IP67 |
Description
The ABB DTPC723A 3EST000210-3450 interface module, a core component in industrial automation, is designed for efficient data exchange and signal conversion under complex operating conditions. This module employs a modular architecture, supports multi-protocol communication, and performs exceptionally well in scenarios such as manufacturing production line control, energy system monitoring, and rail transit signal processing. Its unique redundancy design ensures stable operation even in extreme environments.
Applications
Aluminum power plants: Serving as the communication interface for the rectifier control system, coordinating the high-current regulation of the electrolytic cells.
Large steel mills (cold/hot rolling mills): In high-speed rolling lines, responsible for real-time interface communication between the drivers and the main control system.
Chemical plants (fine chemical plants): Connecting I/O acquisition stations scattered across different areas to achieve centralized monitoring.
Paper mills: Used for synchronous interface control of the paper machine drive system.
Cement plants: Distributed control nodes connecting large equipment such as raw material mills and rotary kilns.
Competitive Advantage
The DTPC723A 3EST000210-3450 Interface Module is positioned as a high-performance industrial communication hub. Its core advantage lies in its simultaneous support for both PROFINET and PROFIBUS protocol stacks, enabling seamless integration between traditional industrial networks and next-generation Ethernet. The module incorporates an intelligent diagnostic system that monitors communication status in real time and automatically optimizes data transmission paths. Its IP67 protection rating, combined with a wide temperature range of -20°C to +60°C, allows it to withstand harsh environments such as dust and humidity.
FAQ
Q: Does the IP67 protection rating of the DTPC723A 3EST000210-3450 mean it can be submerged in water?
A: IP67 allows the module to be submerged in 1 meter of water briefly without damage, ideal for food or pharmaceutical plants requiring frequent rinsing.
Q: Can the DTPC723A 3EST000210-3450 run both PROFINET and PROFIBUS protocols simultaneously?
A: It supports both protocols, but typically one must be selected via DIP switches or software configuration according to fieldbus requirements.
Q: Does its 0.8kg weight indicate weak shock resistance?
A: No. Its lightweight 150x100mm design provides superior shock resistance compared to larger traditional modules, suitable for vibrating machinery.
Q: What is the permissible fluctuation range for the DTPC723A 3EST000210-3450 24V DC supply?
A: Maintain within standard industrial range (±15%) to ensure accurate signal acquisition from the 4DI/2DO interface.
Q: Does the DTPC723A 3EST000210-3450 require preheating when starting at -20°C?
A: No. Its industrial-grade design allows cold starts at -20°C with immediate normal operation.
