DS200DCFBG1BNC power supply board

Overview

Place of Origin:	USA
Brand Name:	GE
Model Number:	DS200DCFBG1BNC
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The DS200DCFBG1BNC is a power supply board specifically manufactured for General Electric's Mark V series of replacement and optional boards. It is an integral component of the Speedtronic Mark V control system, which finds applications in the control and management of wind, steam, and gas turbine automated drive assemblies. This card provides system control level power and supplies electricity to the enclosure fan. It is compatible with various GE brand exciters and drives, including the FC2000, AC2000, DC2000, ME2000, and CB2000 series.

The Mark V Series remains highly esteemed as it is one of the final GE Mark product series to widely incorporate the patented Speedtronic control system technology. The DS200DCFBG1BNC is not the original power supply board for the Mark V Series; that would be the DS200DCFBG1 parent Power Supply Board, which lacks the DS200DCFBG1BNC's three significant product revisions.

Features

High Performance: Operates stably and reliably in industrial environments.

Versatility: Suitable for a variety of applications, such as power system control, factory automation, and machine control.

Reliability: Suitable for various industrial environments and applications.

Wide Operating Temperature Range: From -40°C to 70°C.

Complies with all applicable industry standards.

Applications

This product is widely used in the following areas:

Power Generation and Distribution: Used in power plants and substations to ensure reliable power supply to power systems.

Industrial Automation: Used in automation systems, PLCs (Programmable Logic Controllers), and other industrial control equipment to ensure precise control in production processes.

Food and Beverage Processing Control: Can be used to control mixing, cooking, and packaging processes in food and beverage processing.

Installation and Support

Installation parameters provided with the board and drive must be followed to ensure proper operation. An illustrated guide to wiring and installing the board is available in the device’s manual and datasheet. The DS200DCFBG1BNC should be handled as a static-sensitive product and may have potentially lethal surface voltages during or after use. General Electric originally provided technical support for all Mark V series boards.

Frequently Asked Questions

What circuits are included with DS200DCFBG1BNC?

DS200DCFBG1BNC has circuits for control-level power supplies, DS200DCFBG1BNC has circuits for motor field power circuits and driver circuits for the motor field SCR gate pulse generators, and DS200DCFBG1BNC has circuits that monitor several AC line and DC motor signals.

What do the VCO circuits on DS200DCFBG1BNC do?

The VCO or voltage-controller oscillator circuits on DS200DCFBG1BNC convert input voltages to frequency signals.

How much voltage does DS200DCFBG1BNC get from the CPT?

DS200DCFBG1BNC gets 38 VAC from the CPT or control power transformer.

Where can I find the manual for DS200DCFBG1BNC?

We can send you the manual for DS200DCFBG1BNC. The manual for DS200DCFBG1BNC is Manual GEI-100028 and the manual is the GE Industrial Control Systems Power Supply Board Manual. Hopefully, this instructional manual remains available online well into the future, as General Electric is currently removing many members of obsolete product series including the Mark V every day in troves.
