Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
CC-TAIM01 51305959-175 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
CC-TAIM01 51305959-175 |
|
Product Type: |
Low-Level Analog Input Module |
|
Dimensions: |
18.5 × 15 × 7.5 cm |
|
Weight: |
0.3 kg |
|
Input Channels: |
64 fully isolated analog inputs |
|
Input Type: |
Low-level analog signals |
|
Scan Rate: |
Up to 64 channels per second |
|
Isolation: |
Channel-to-channel and channel-to-system isolation |
|
Current Rating: |
1.0 A / 250 V |
|
Operating Temperature: |
0°C to 60°C |
Description
The Honeywell CC-TAIM01 51305959-175 is a Low-Level Analog Input Module used for Honeywell's distributed control systems (DCS), such as the Experion PKS platform. This module can handle low-level analog signals, including thermocouples and RTDs, ensuing precise temperature and process variable measurements in industrial environments.
Applications
Thermal Power Plants: Connects boiler thermocouples.
Chemical Plants: Monitors reactor temperature.
Steel Mills: Transmits blast furnace temperature signals.
Cement Plants: Collects kiln temperature rise data.
Glass Manufacturing Plants: Outputs furnace heat signals.
Features
High Channel Density: Supports 64 isolated analog inputs for compact signal acquisition.
Fast Data Acquisition: High scan rate ensures real-time responsiveness in control systems.
Low Noise Design: Engineered to minimize electrical interference and signal distortion.
Reliable Isolation: Prevents crosstalk and enhances system safety.
Modular Integration: Compatible with Honeywell's IOTA and Series C platforms.
Industrial Durability: Built for continuous operation in harsh process environments.
FAQ
Q: What signal type and channel count does the CC-TAIM01 51305959-175 support?
A: Supports 64-channel fully isolated low-level analog input signals.
Q: What is the maximum data scan rate of the CC-TAIM01 51305959-175?
A: Capable of scanning and acquiring 64 channels per second.
Q: What is the isolation structure of the CC-TAIM01 51305959-175?
A: Supports dual isolation between channels and between channel and system.
Q: What are the rated current and voltage of the CC-TAIM01 51305959-175?
A: Rated electrical specification is 1.0 A / 250 V.
Q: What is the operating temperature range of the CC-TAIM01 51305959-175?
A: Operating temperature range is 0°C to 60°C.
