Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
8C-PDIL51 51454359-175 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
8C-PDIL51 51454359-175 |
|
Part name |
Digital Input Module |
|
Dimensions |
6x15.7x14.2cm |
|
Weight |
0.3kg |
|
Input channels |
32 digital inputs |
|
Input voltage range |
18–30 VDC |
|
Input current |
6 mA typical @ 24 VDC |
|
Isolation |
1500 VDC channel-to-backplane |
|
Response time |
Maximum 5 ms |
|
Operating temperature |
-40°C to +70°C |
|
Power consumption |
Maximum 2.5 W |
|
Certifications |
CE, UL, ATEX compliant |
Description
Honeywell 8C-PDIL51 51454359-175 is a 32-channel 24V DC digital input module designed for industrial automation systems, offering high-density input capabilities and robust performance.
Applications
Oil Refinery: Used to monitor the limit status of valves in long-distance pipelines and the interlocking of pump units, ensuring intrinsic safety through high-level isolation.
Fine Chemical Plant: Integrated into automated reaction systems, it collects discrete signals from level and pressure switches in real time to ensure process flow logic.
Large Pharmaceutical Plant: Used in cleanroom filling control systems; its high-density 32-channel design effectively saves cabinet space in precision control rooms.
Features
Analog Input: Accepts continuous sensor signals such as temperature, pressure, and flow.
High Precision: Converts analog signals accurately to support reliable control data.
High Stability: Uses advanced design to ensure stable operation and low failure rates.
Easy Integration: Easily integrates into DCS for centralized plant monitoring and control.
Precautions
Compatibility Check: When purchasing and using the module, please ensure it is compatible with your control system and application.
Correct Installation: Please install and configure the module correctly according to the installation guide provided by the supplier to ensure its proper functioning.
Regular Maintenance: Regular inspection and maintenance of the module can extend its service life and improve its performance.
FAQ
Q: How many channels does the 8C-PDIL51 51454359-175 support, and what is its input voltage range?
A: It supports 32 digital inputs and operates with 18–30 VDC industrial signals.
Q: What is the typical current consumption of the 8C-PDIL51 51454359-175 at 24 VDC?
A: Typical input current per channel is 6 mA under 24 VDC supply.
Q: How is the isolation capability of the 8C-PDIL51 51454359-175?
A: It provides 1500 VDC isolation from the baseboard, effectively suppressing field electrical noise.
Q: How fast is the signal response of the 8C-PDIL51 51454359-175?
A: Maximum response delay is only 5 ms for millisecond-level logic transitions.
Q: Does the 8C-PDIL51 51454359-175 consume much power, and is it explosion-proof certified?
A: Maximum power consumption is 2.5 W, and it complies with ATEX, CE, and UL standards.
