Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5500-577 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
5500-577 |
|
Product Name |
Programmable Logic Controller |
|
Operating Voltage |
230 V AC |
|
Input Current |
5 A |
|
Output Current |
3 A |
|
Control Range |
0–10 V DC |
|
Power Consumption |
25 W |
|
Operating Temperature |
-20°C to +55°C |
|
Storage Temperature |
-40°C to +85°C |
|
CPU Speed |
1.2 GHz |
|
Memory |
512 MB RAM |
|
Storage |
4 GB Flash Memory |
Description
The Woodward 5500-577 is a Programmable Logic Controller. In industrial automation control systems, it is primarily responsible for receiving status signals from various locations in the field and performing calculations and judgments according to its pre-programmed logic.
Applications
Automotive Manufacturing: Coordinates robotic arms and conveyor systems for precise assembly control.
Food Processing: Regulates drives and valves for automated temperature and speed control.
Textile & Dyeing Plants: Ensures stable multi-color dyeing and synchronized fabric movement in harsh environments.
Smart Warehousing & Logistics: Handles sensor-heavy sorting lines and local data storage for fast processing.
Water Treatment Plants: Manages pump cycling and valve control for simplified field operation.
Troubleshooting & Solutions
Program lag or crashes: Even with 512 MB RAM, poor loop design or frequent interrupts can overload CPU. Optimize polling cycles to reduce load.
0–10 V DC signal inaccuracy: Often caused by EMI. Keep signal lines separate from 230 V AC cables and ensure proper single-end shielding ground.
Unable to save logs/configuration: Frequent flash writes may damage 4 GB memory. Optimize storage logic to reduce repeated erase/write cycles.
FAQ
Q: What is the CPU clock speed of the 5500-577?
A: CPU speed is 1.2 GHz.
Q: How much RAM and flash storage does the 5500-577 include?
A: Includes 512 MB RAM and 4 GB flash storage.
Q: What AC input voltage is required to operate the 5500-577?
A: Operating voltage is 230 V AC.
Q: What is the control signal adjustment range of the 5500-577?
A: Control range is 0–10 V DC.
Q: What is the total power consumption of the 5500-577 during operation?
A: Power consumption is 25 W.
