Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5466-348 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5466-348 |
|
Product Type |
NetCon SIO Module |
|
Dimensions |
2.5 × 24.6 × 26.1 cm |
|
Weight |
0.95 kg |
|
Protocol |
RS-485 UART |
|
Baud Rate |
417 kbaud |
|
Parity |
None |
|
Data Bits |
8 |
|
Stop Bits |
1 |
|
Update Rate |
5 ms (critical parameters, one driver per port) |
|
Position Command |
16-bit high-accuracy command (low noise) |
|
Isolation |
Galvanic isolation |
|
Mounting Type |
DIN rail mount |
Functional Description
5466-348 is a Netcon sIo Module developed by Woodward. sIO Module is equipped with three RS-485 ports. Each port is intended for use with EM or GS/LQ Digital Actuator Drivers. Every 5 ms, one driver is allowed for each port. The address switches of each driver must match the driver number in the GAP application program. The Universal Digital Drivers' RS-485 communications can be used for monitoring or control.
Applications
Thermal power plant: Used in turbine DEH systems with independent RS-485 drivers and fast update cycles for precise valve control.
Heavy chemical plant: Installed in compressor control racks with high-speed serial links for anti-surge valve regulation.
Marine industry: Applied in diesel engine governor systems with DIN rail mounting for vibration-resistant operation.
Aero engine test facility: Used in fuel metering control for high-precision closed-loop engine test control.
Features
With one driver per port, the update rate for critical parameters is 5 ms.
Interface for Digital Actuator Drivers
Each RS-485 port can operate at a different rate group.
Each driver's communication fault is detected, and drivers with comm faults are disabled.
Remote monitoring of driver parameters
Remote driver parameter configuration
FAQ
Q: What communication protocol does the 5466-348 use?
A: Uses RS-485 UART communication protocol.
Q: What is the communication baud rate of the 5466-348?
A: Communication baud rate is 417 kbaud.
Q: How are data bits and stop bits configured for serial communication on the 5466-348?
A: Configured as 8 data bits and 1 stop bit (no parity).
Q: What is the update rate of key parameters for the 5466-348?
A: Update rate is 5 ms.
Q: What instruction format is used for position commands in the 5466-348?
A: Uses 16-bit high-precision instruction format.
