Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5464-211 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5464-211 |
|
Product Type |
Integrating Actuator Driver Module |
|
Dimensions |
2.6 × 24.8 × 26.2 cm |
|
Weight |
1.08 kg |
|
Input Voltage |
24 VDC |
|
Operating Temperature |
-40°C to +85°C |
|
Physical Structure |
Standard rack rail slot card design |
|
Input Signal Response |
Floating input design (internally pulled up to +5 VDC) |
|
Module Power Supply |
Internal 5 VDC via system rack backplane bus |
|
Output Current |
1 A |
|
Communication Interface |
RS-485 |
|
Protection |
Overload, overvoltage, short-circuit |
Description
5464-211 is an Integrating Act Driver Module developed by Woodward. One of the primary functions of the module is to convert control signals from the control system into precise actuator movements. It receives input signals from the control system, including position, speed, and torque control commands.
Applications
Thermal power plant: Used in DEH turbine control as high-current output stage driving hydraulic servo valves under wide-temperature industrial conditions.
Heavy chemical plant: Installed in compressor anti-surge racks, using RS485 communication for fast, high-precision control of gas proportional valves.
Shipbuilding yard: Applied in marine diesel engine governor systems, with rack-mounted design resisting continuous high-frequency vessel vibration.
Steel plant: Used for blast furnace blowers and TRT systems, controlling fuel and air valves with built-in short-circuit and overload protection.
Features
Integration Capability: The module integrates with the control system, providing efficient communication and compatibility. Its design ensures optimal performance in complex automation setups.
Precise Actuation: The module is engineered to deliver precise control of actuators, enabling smooth and accurate operation in mechanical systems.
Reliability: Built for demanding industrial environments, the module is known for its durability and long service life, even under challenging conditions.
Ease of Installation: Designed for user-friendly installation, the module simplifies system configuration and reduces setup time.
Fault Tolerance
Each kernel section of the MicroNet TMR controller independently monitors all input data, performs all application calculations, and generates all output values and responses. This control's architecture allows it to operate without being affected by a single point of failure. The system's CPU fault-tolerant 3-2-0 logic
designed for reliability and safety, allows the control to function normally with any CPU module failing or removed and ensures a safe shutdown with multiple CPU failures.
A 3-2-1-0 analog I/O fault tolerance logic allows the control to function normally even if one or both analog modules fail or are removed. A 3-2-1-0 discrete I/O fault tolerance logic allows the control to function normally even if one or two discrete modules fail or are removed. A 2-1-0 power supply fault tolerance logic allows the control to function normally even if one of the power supplies fails or is removed.
FAQ
Q: What DC supply voltage is required for the 5464-211 card?
A: Input voltage is 24 VDC.
Q: What type of physical structure does the 5464-211 use?
A: Uses a standard rack rail slot card design.
Q: To what voltage is the internal floating input of the 5464-211 pulled up?
A: Pulled up to +5 VDC.
Q: How is the 5 VDC operating power supplied to the 5464-211 module?
A: Obtained through the system rack backplane bus.
Q: What is the maximum output current supported by the 5464-211?
A: Output current is 1 A.
