Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5462-718 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5462-718 |
|
Product Type |
MicroNet Speed Sensor Module |
|
Dimensions |
6.3 × 3 × 1.8 cm |
|
Weight |
0.38 kg |
|
Sensor Type |
Hall Effect / Magnetic Pickup (MPU) compatible |
|
Output Voltage |
0–10 V (proportional to speed) |
|
Sensitivity |
10 mV / 1000 rpm |
|
Accuracy |
±1% of reading |
|
Linearity |
±0.5% of full scale |
|
Operating Temperature |
-40°C to +85°C |
|
Storage Temperature |
-40°C to +125°C |
Description
The 5462-718 is a precision-engineered Speed Sensor Module used for the Woodward MicroNet control platform. It serves as a specialized frequency-to-voltage interface, measuring the rotational speed of shafts in engines, pumps, fans, and machine tool spindles. By utilizing Hall effect technology, the module provides a stable and accurate representation of rotational velocity, which is critical for governor regulation and system safety monitoring.
Applications
Shipbuilding yards: Used in marine engine and auxiliary speed monitoring with stable analog signals to control rooms.
Thermal power plants: Used in turbine and fan overspeed protection with strong anti-interference capability.
Heavy chemical plants: Used in compressor and pump VFD loops for high-temperature cabinet environments.
Automotive engine plants: Used in drivetrain test benches for accurate full-range speed feedback.
Aerospace manufacturing plants: Used in rotor balancing systems with flexible storage and maintenance support.
Feature
Signal processing and stability
The module includes an amplifier and filtering circuitry to maintain signal quality in high-interference environments. It converts raw speed pulses into a 0–10 V output, enabling stable CPU control under varying loads.
Adaptive speed monitoring
It supports a wide speed range for different applications. With calibrated sensitivity, it provides high-resolution feedback for detecting small changes in machine behavior and mechanical wear.
Industrial ruggedness and diagnostics
Built for harsh environments, it operates under extreme temperatures and includes an LED status indicator. It supports fault detection via high/low setpoints to quickly identify sensor or wiring issues.
FAQ
Q: What type of sensors is the 5462-718 compatible with?
A: Supports compatibility with Hall Effect / Magnetic Pickup sensors.
Q: What is the output voltage range of the 5462-718?
A: Output voltage is 0–10 V (proportional to speed).
Q: What is the speed measurement sensitivity of the 5462-718?
A: Sensitivity is 10 mV / 1000 rpm.
Q: What is the speed measurement accuracy of the 5462-718?
A: Accuracy is ±1% of reading.
Q: What is the linearity of the 5462-718 across full scale?
A: Linearity is ±0.5% of full scale.
