Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5441-693 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5441-693 |
|
Product Type |
Discrete I/O Module |
|
Dimensions |
45.6 × 12.2 × 9.5 cm |
|
Weight |
1.98 kg |
|
Input Channels |
24 |
|
Input Type |
Optically isolated discrete input |
|
Update Time |
5 ms |
|
Time Stamping |
1 ms resolution |
|
Isolated 24 VDC Contact Supply |
400 mA maximum |
|
Input Voltage Range |
10–30 VDC |
|
Current Consumption |
Max 100 mA |
|
Operating Temperature |
-40°C to +85°C |
|
Communication Interface |
RS-485 |
|
Resolution |
16-bit |
|
Signal Range (Analog) |
0–10 VDC |
|
Output Points |
8 isolated points |
|
Output Current Range |
4–20 mA |
Description
5441-693 is a Discrete l/O Module developed by Woodward. It is used to be used in conjunction with a programmable logic controller (PLC) system. This module is specifically classified as a relay module, indicating that it utilizes relays to control and switch electrical circuits. It offers a total of 13 relay circuits, allowing for multiple control and switching functionalities within a single module. As a Discrete I/O Module, it plays a pivotal role in enhancing the capabilities of programmable logic controller (PLC) systems.
Applications
Gas Turbine Plants: Captures breaker and relay sequences for turbine protection using high-precision event timing.
Deep-Sea Drilling Platforms: Operates in extreme temperatures to control valve positions in outdoor cabinet environments.
Thermal Power Plants: Uses isolated power and serial communication to drive field contacts and transmit data to control systems.
Fine Chemical Plants: Provides high-resolution signal acquisition for accurate pressure and vacuum process control.
Rail Transit Equipment Plants: Enables fast synchronized relay monitoring for vibration-resistant locomotive test systems.
Features
Modules slide into chassis guides and connect to the motherboard, secured by two front-panel screws. Top and bottom handles allow easy removal by disengaging connectors.
Single interface port connects the module to the PLC for control signals and status communication.
13 relay circuits enable switching and monitoring of multiple electrical loads via PLC commands.
FAQ
Q: How many input channels does 5441-693 include?
A: It includes 24 input channels.
Q: What type of discrete input does 5441-693 use?
A: It uses optically isolated discrete inputs.
Q: What is the timestamp resolution of 5441-693?
A: The timestamp resolution is 1 ms.
Q: What is the analog signal range of 5441-693?
A: The analog signal range is 0–10 VDC.
Q: How many isolated output points does 5441-693 have?
A: It has 8 isolated output points.
