Overview
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330910-00-18-10-02-00 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Unthreaded Length Option: |
0 mm |
|
Overall Case Length Option: |
180 mm |
|
Cable Length Option: |
1.0 meter (39 in) |
|
Connector and Cable Option: |
Miniature coaxial ClickLoc connector, standard cable |
|
Agency Approval Option: |
Not required |
|
Probe Case Thread: |
M10X1 thread |
|
Maximum Length of Thread Engagement: |
15 mm |
|
Dimension: |
1.8x1.6x108cm |
|
Weight: |
0.14kg |
Description
The 330910-00-18-10-02-00 3300 NSv Proximity Probe is an eddy-current displacement probe used in automation protection panels for compressors, turbines, and pumps. The 330910-00-18-10-02-00 3300 NSv Proximity Probe features an M10×1 threaded AISI 304 stainless steel body with a long 180 mm case, allowing installation through deep bearing housings. Using a PPS probe tip and 1.5 mm linear range, the 330910-00-18-10-02-00 3300 NSv Proximity Probe measures shaft radial vibration and axial movement with a recommended 1.0 mm gap.
The 330910-00-18-10-02-00 3300 NSv Proximity Probe includes a 1.0 m standard cable and miniature coaxial ClickLoc connector for cabinet wiring (0.2–1.5 mm²). Output resistance is 50 Ω and supply sensitivity is below 2 mV/V, allowing direct signal input to DCS or PLC monitoring modules. Operating from −52 °C to +177 °C, the 330910-00-18-10-02-00 3300 NSv Proximity Probe provides displacement, keyphasor pulse, and rotor position signals for rotating equipment shutdown control.
Applications
Mount 330910-00-18-10-02-00 3300 NSv Proximity Probe in recessed compressor bearing block
The long 180 mm body lets 330910-00-18-10-02-00 3300 NSv Proximity Probe pass through thick housings and position the PPS tip close to the shaft. With a 1.5 mm linear measurement span and 1.0 mm set gap, 330910-00-18-10-02-00 3300 NSv Proximity Probe delivers displacement voltage to monitoring cards for real-time vibration tracking.
Read turbine thrust collar displacement
Facing the thrust disk, 330910-00-18-10-02-00 3300 NSv Proximity Probe converts axial movement into voltage output. The 50 Ω output allows 330910-00-18-10-02-00 3300 NSv Proximity Probe to wire directly into PLC protection input channels without external resistors.
Track vibration on small pump shafts
With the M10×1 threaded stainless housing, 330910-00-18-10-02-00 3300 NSv Proximity Probe fits compact bearing brackets. The 7.87 V/mm scale factor enables 330910-00-18-10-02-00 3300 NSv Proximity Probe to send precise displacement levels to DCS monitoring modules.
Specifications
|
Probe Temperature Range: |
-52°C to +177°C (-62°F to +351°F) |
|
Storage Temperature: |
-52°C to +177°C (-62°F to +351°F) |
|
Probe Tip Material: |
Polyphenylene sulfide (PPS) |
|
Probe Case Material: |
AISI 304 stainless steel (SST) |
|
Field Wiring: |
0.2 to 1.5 mm2 (16 to 24 AWG)[0.25 to 0.75 mm2 (18 to 23 AWG) with ferrules] |
|
Linear Range: |
1.5 mm (60 mils) |
|
Recommended Gap Setting: |
1.0 mm (40 mils) |
|
Output resistance: |
50 Ω |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage |
Competitive Advantage
Insert probe into deep installation point without machining
The 180 mm case length allows 330910-00-18-10-02-00 3300 NSv Proximity Probe to reach the shaft inside thick covers, so maintenance teams install 330910-00-18-10-02-00 3300 NSv Proximity Probe without enlarging mounting holes.
Deliver consistent displacement voltage under supply change
Power variation causes less than 2 mV/V output change. 330910-00-18-10-02-00 3300 NSv Proximity Probe maintains usable measurement for protection modules and alarm relays.
Work near hot bearings and seals
Operating range from −52 °C to +177 °C enables 330910-00-18-10-02-00 3300 NSv Proximity Probe to monitor compressors and turbines where casing temperature rises during operation.
Secure cable connection in vibrating machinery
The miniature coaxial ClickLoc connector locks firmly. 330910-00-18-10-02-00 3300 NSv Proximity Probe keeps signal wiring attached even during continuous rotor vibration.
