Overview
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-06-20-01-00 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Unthreaded Length Option(Minimum unthreaded length): |
00 mm |
|
Overall Case Length Option(Minimum case length): |
60 mm |
|
Total Length Option: |
2.0 meters (6.6 feet) |
|
Connector and Cable-Type Option: |
Miniature coaxial ClickLoc connector with connector protector, standard cable |
|
Agency Approval Option: |
Not required |
|
Probe Case Thread: |
M10x1 |
|
Maximum Length of Thread Engagement: |
15 mm |
|
Dimension: |
113x2x1.5cm |
|
Weight: |
0.14kg |
Description
The 330104-00-06-20-01-00 3300 XL 8 mm Proximity Probe delivers voltage output proportional to shaft displacement up to 2 mm, supporting both static position and dynamic vibration measurements in automated systems. With a 60 mm case, M10x1 thread, and 2-meter standard cable with 69.9 pF/m capacitance, the 330104-00-06-20-01-00 3300 XL transducer integrates seamlessly into PLCs and condition monitoring networks. Its 50 Ω output resistance and <2 mV/V supply sensitivity ensure accurate data acquisition for fluid-film bearings and Keyphasor speed applications. The ClickLoc connector with protector allows quick installation and replacement in industrial automation environments. Optional FluidLoc configuration prevents oil intrusion, maintaining signal integrity during continuous automated operations. Operating from -52°C to +177°C, the 330104-00-06-20-01-00 3300 XL probe delivers reliable measurement for predictive maintenance and real-time control.
Applications
Monitor Shaft Vibration in Fluid-Film Bearings
The 330104-00-06-20-01-00 3300 XL probe measures dynamic vibration up to 2 mm linear range, using its 50 Ω output and <2 mV/V supply sensitivity to provide precise real-time vibration data for fluid-film bearing machines in automated control systems.
Position Measurement for Rotating Equipment
With a 60 mm case and M10x1 probe thread, the 330104-00-06-20-01-00 3300 XL accurately measures shaft position, enabling automated feedback to PLCs or DCS for precise alignment and control.
Keyphasor and Speed Detection
The 2-meter standard cable and miniature ClickLoc connector allow the 330104-00-06-20-01-00 3300 XL probe to detect shaft keyphasor signals, supporting speed measurement and automated monitoring of turbine and motor operations.
Integration into Condition Monitoring Systems
The 330104-00-06-20-01-00 3300 XL probe’s low capacitance (69.9 pF/m) and optional FluidLoc cable configuration make it suitable for automated predictive maintenance systems, preventing oil ingress while maintaining accurate signal transmission.
Specifications
|
Operating and Storage Temperature: |
-52°C to +177°C (-62°F to +350°F) |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage |
|
Output Resistance: |
50 Ω |
|
Extension Cable Capacitance: |
69.9 pF/m (21.3 pF/ft) typical |
|
Field Wiring: |
0.2 to 1.5 mm2 (16 to 24 AWG) |
|
Linear Range: |
2 mm (80 mils) |
Competitive Advantage
High Accuracy in Automated Measurement
The 330104-00-06-20-01-00 3300 XL transducer provides linear output over 2 mm range with minimal supply voltage sensitivity (<2 mV/V), delivering precise readings for automated vibration and position monitoring.
Robust Installation and Cable Security
The probe’s ClickLoc connector with protector and patented CableLoc design ensures 330 N pull strength, allowing secure automated installations and reducing downtime during sensor replacement.
Long-Term Data Integrity
Operating from -52°C to +177°C, the 330104-00-06-20-01-00 3300 XL maintains accurate readings across extreme industrial conditions, enabling continuous automated data acquisition without recalibration.
Flexible Integration with Automation Systems
Backward compatibility with other 3300 XL series probes and standard extension cables allows the 330104-00-06-20-01-00 3300 XL to be easily swapped or upgraded in automated measurement and control networks without additional configuration.
