330103-06-13-05-02-CN 3300 XL 8 mm Proximity Probes

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	330103-06-13-05-02-CN
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

330103-06-13-05-02-CN is a 3300 XL 8 mm Proximity Probe engineered for automation vibration and position monitoring in hazardous industrial environments. 330103-06-13-05-02-CN features M10x1 thread with 60 mm minimum unthreaded length and 130 mm minimum case length, enabling deep installation inside large bearing housings. Maximum thread engagement is 15 mm.

The total cable length of 330103-06-13-05-02-CN is 0.5 meter (1.6 ft), reducing signal path distance in compact control cabinets. Output resistance is 50 Ω, and extension cable capacitance is 69.9 pF/m, ensuring defined electrical transmission. Linear measurement range reaches 2 mm (80 mils), converting shaft gap change directly into proportional voltage output. Supply sensitivity remains below 2 mV per volt change.

Operating from −52°C to +177°C, 330103-06-13-05-02-CN performs in turbines, compressors, and motors. With CSA, ATEX, and IECEx approvals, 330103-06-13-05-02-CN can be installed in explosive gas zones. 330103-06-13-05-02-CN supports radial vibration measurement, axial displacement tracking, Keyphasor reference, and rotational speed monitoring within automation systems.

Applications

Insert Probe Through 130 mm Case to Reach Shaft Surface

330103-06-13-05-02-CN uses a 130 mm minimum case length and 60 mm unthreaded section to extend through thick bearing covers. With M10x1 thread and maximum 15 mm engagement, 330103-06-13-05-02-CN can be fixed firmly while maintaining a correct gap inside the 2 mm linear range. This configuration allows direct shaft displacement detection in heavy turbine housings.

Connect Short 0.5 m Cable Inside Compact Control Cabinet

The 0.5 meter cable of 330103-06-13-05-02-CN reduces wiring length between probe and monitoring module. With 69.9 pF/m capacitance, total capacitance load remains low over the short distance. The 50 Ω output resistance of 330103-06-13-05-02-CN supports direct interface to automation racks using 0.2–1.5 mm² conductors.

Monitor Shaft Movement Across 2 mm Measurement Span

330103-06-13-05-02-CN converts conductive surface distance change into proportional voltage within a defined 2 mm (80 mils) range. When shaft motion approaches the limit of this span, automation systems receive measurable voltage variation for alarm or shutdown logic.

Install in Explosive Gas Area with Certified Approval

With CSA, ATEX, and IECEx approvals, 330103-06-13-05-02-CN can operate inside classified oil and gas zones. The −52°C to +177°C operating range enables 330103-06-13-05-02-CN to function in outdoor pipeline compressors and high temperature steam turbine enclosures.

Specifications

Competitive Advantage

Limit Output Drift During Power Variation

Supply sensitivity below 2 mV per volt means if supply changes by 1 V, 330103-06-13-05-02-CN output shifts less than 2 mV. This quantified electrical behavior keeps displacement calculation within defined tolerance.

Provide Defined Electrical Path with 50 Ω Output

The fixed 50 Ω impedance of 330103-06-13-05-02-CN reduces signal reflection when connected to standard proximity monitoring modules. Combined with short cable length, 330103-06-13-05-02-CN maintains predictable signal transmission.

Enable Deep Mounting in Large Rotating Equipment

The extended 130 mm case and 60 mm smooth section allow 330103-06-13-05-02-CN to be installed where shallow probes cannot reach the shaft. This mechanical structure expands installation options in turbines, compressors, and large motors used in automation systems.
