3300/16 XY/GAP Dual Vibration Monitor , China 3300/16 XY/GAP Dual Vibration Monitor Manufacturers, Suppliers, Factory

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	3300/16
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Full-scale Range Option	0-500 µm pp
Transducer Input Option	3300 8 mm, 3300 XL 8mm or 7200 5 mm and 8 mm Proximitor Sensor, 200 mV/mil
Alarm Relay Option	Quad Relay (Epoxy-sealed only)
Agency Approval Option	Not required
Safety Barrier Option	None
Trip Multiply Option	3X
Product Name	3300/16 XY/Gap Dual Vibration Monitor
Function	Measures two independent channels of radial vibration and average shaft position (gap); accepts inputs from two proximity probe/Proximitor® systems
Signal Inputs	Accepts one or two proximity probe signals
Input Impedance	10 kΩ
Sensitivity	100 mV/mil (4 V/mm) or 200 mV/mil (8 V/mm), user-programmable
Power Consumption	2 W nominal
Signal Conditioning Accuracy ±25°C (+77°F)	±0.33% typical; ±1% maximum; ±2% maximum with 2X Trip Multiply; ±3% maximum with 3X Trip Multiply
Frequency Response	User-programmable: 4–4,000 Hz (240–240,000 cpm) or 1–600 Hz (60–36,000 cpm); -3 dB nominal
Output Impedance (Voltage)	100 Ω; minimum load resistance 10 kΩ
Voltage Compliance (Current Outputs)	0–+12 Vdc across load; load resistance 0–600 Ω when using +4 to +20 mA option
Dimension:	5x32.2x20.3cm
Weight:	0.96 kg

Description

The 3300/16 XY/Gap Dual Vibration Monitor measures two independent radial vibration channels and average shaft position (gap) in industrial machinery. The 3300/16 XY/Gap Dual Vibration Monitor accepts inputs from one or two 3300 8 mm, 3300 XL 8 mm, or 7200 Proximitor® sensors with 10 kΩ input impedance and user-programmable sensitivity of 100 mV/mil or 200 mV/mil. Full-scale range is 0–500 µm pp, with digitally adjustable alarm setpoints repeatable within ±0.39% of full-scale.

The 3300/16 XY/Gap Dual Vibration Monitor provides user-programmable frequency response from 4–4,000 Hz or 1–600 Hz and ±0.33% signal conditioning accuracy at 25°C, increasing to ±3% with 3X Trip Multiply. Voltage output impedance is 100 Ω, and current output supports 0–+12 Vdc or +4 to +20 mA across 0–600 Ω load. Display resolution is ±1.6% of full-scale on an 83 mm vertical LCD. With nominal power consumption of 2 W, the 3300/16 XY/Gap Dual Vibration Monitor operates from 0°C to +65°C and stores at -40°C to +85°C, providing continuous monitoring for automated vibration and shaft position systems.

Applications

Measure dual radial vibration in turbines and compressors
The 3300/16 XY/Gap Dual Vibration Monitor captures independent vibration channels, allowing operators to detect imbalance or bearing wear using 0–500 µm pp range and ±0.33% signal accuracy.

Monitor average shaft position for gap alarms
Using Proximitor® inputs and ±1 rpm speed accuracy, the 3300/16 XY/Gap Dual Vibration Monitor tracks shaft position and triggers gap alarms with 6-second delay, protecting machinery from misalignment.

Provide alarm outputs with 3X Trip Multiply
The 3300/16 XY/Gap Dual Vibration Monitor drives quad relays for trip and alarm functions, applying amplified 3X signals while maintaining ±3% conditioning accuracy for automated shutdown sequences.

Integrate vibration data into automated control systems
The 3300/16 XY/Gap Dual Vibration Monitor outputs voltage (0–+12 Vdc) or current (+4 to +20 mA) signals to PLCs or DCS systems for continuous monitoring and automated response.

Specifications

Alarm Setpoints Resolution	Digitally adjustable 0–100% of full-scale; set within LCD resolution ±1.6%
Alarm Setpoints Repeatability	Once set, repeatable within ±0.39% of full-scale
Gap Alarm Time Delay	6 seconds
Operating Temperature	0°C to +65°C (+32°F to +150°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Relative Humidity	Up to 95%, non-condensing
Display Resolution	Within ±1.6% of monitor full-scale
Display Size	83 mm (3.25 in), vertical dimension

Competitive Advantage

Dual-channel vibration and gap monitoring in one module
The 3300/16 XY/Gap Dual Vibration Monitor measures two radial channels and average shaft position simultaneously, reducing the number of modules needed per machine.

Digitally adjustable alarm setpoints with high repeatability
The 3300/16 XY/Gap Dual Vibration Monitor sets alarm thresholds within ±0.39% of full-scale, ensuring consistent protection across repeated adjustments.

User-programmable frequency response for multiple machinery types
The 3300/16 XY/Gap Dual Vibration Monitor allows selection of 4–4,000 Hz or 1–600 Hz ranges, adapting to turbines, compressors, and motors without external filters.

Low-power operation with clear LCD display
With only 2 W consumption and an 83 mm vertical LCD displaying ±1.6% resolution, the 3300/16 XY/Gap Dual Vibration Monitor supports continuous monitoring in automated industrial control panels.
