200350-12-00-00 Accelerometer, China 200350-12-00-00 Accelerometer Manufacturers, Suppliers, Factory

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	200350-12-00-00
Minimum Order Quantity:	1
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Mounting Stud :	M8x1.25 Adhesive Stud Mount
Tolerance:	100 mV/g ± 20% (10.2 mV/m/s^2 ±20%)
Approvals:	No Approvals
Dimension:	5.1x2x2cm
Weight:	0.05kg

Description

The 200350-12-00-00 Accelerometer is a rugged, high-accuracy vibration sensor developed for industrial automation, machinery condition monitoring, and predictive maintenance systems. Designed as a general-purpose piezoelectric accelerometer, the 200350-12-00-00 accelerometer delivers a stable 100 mV/g sensitivity across a wide 0.5 Hz to 10,000 Hz (30–600,000 cpm) frequency range, enabling precise vibration measurement on rotating and reciprocating machinery. This wide bandwidth makes the accelerometer highly effective for automation applications that require early fault detection, including imbalance, misalignment, bearing wear, and gear mesh defects.

Housed in a hermetically sealed stainless steel enclosure, the 200350-12-00-00 accelerometer is engineered to withstand harsh industrial automation environments. It supports M8x1.25 adhesive stud mounting, operates reliably from -54°C to +121°C, and survives shock levels up to 5,000 g peak, ensuring long-term durability in high-vibration applications. With ±50 g measurement range, ±1% amplitude linearity, and low broadband electrical noise of 350 µg, this accelerometer provides clean, repeatable vibration data for automated monitoring platforms. Compatible with constant current excitation systems operating from 18 to 28 VDC, the 200350-12-00-00 accelerometer integrates seamlessly into automated condition monitoring architectures, supporting continuous asset health assessment and optimized maintenance strategies.

Applications

Application 1: Continuous Vibration Monitoring of Rotating Machinery

In industrial automation systems, the 200350-12-00-00 accelerometer is widely used for continuous vibration monitoring of motors, pumps, fans, and compressors. Its ±50 g measurement range and 100 mV/g sensitivity enable accurate detection of vibration amplitude changes, allowing automated systems to identify imbalance or looseness before mechanical failure occurs.

Application 2: Bearing Fault Detection in Automated Plants

With a frequency response extending to 10,000 Hz, this accelerometer captures high-frequency vibration signatures generated by rolling element bearing defects. Automation platforms analyze these signals to detect early-stage spalling, reducing unplanned downtime and maintenance costs.

Application 3: Gearbox Condition Monitoring

The 200350-12-00-00 accelerometer supports reliable gearbox monitoring by measuring vibration harmonics related to gear mesh frequencies. Its ±1% amplitude linearity ensures consistent trend data, which is essential for automated diagnostics and long-term performance analysis.

Application 4: Machinery Protection in Harsh Environments

Installed on critical assets in harsh industrial environments, the accelerometer’s hermetic stainless steel housing and 5,000 g shock survivability protect the sensing element from contamination and mechanical shock. This reliability supports automation systems that require continuous operation under extreme conditions.

Application 5: Predictive Maintenance and Trend Analysis

When connected to constant current input modules, the 200350-12-00-00 accelerometer provides high-quality vibration data for predictive maintenance algorithms. Its low noise floor of 350 µg improves trend accuracy, enabling data-driven maintenance planning in automated facilities.

Specifications

Sensitivity:	100 mV/g ±20% (10.2 mV/m/s^2 ±20%)
Frequency Range (±3 dB) :	30-600,000 cpm (0.5- 10,000 Hz)
Measurement Range:	± 50 g
Transverse Sensitivity:	≤ 7%
Amplitude Linearity :	± 1%
Mounted Resonant Frequency:	1500 kcpm (25 kHz)
Broadband Electrical Noise (1-10kHz) :	350 µg (3,434 µm/s2)
Output Bias Voltage:	8 to 12 VDC
Excitation Voltage:	18 to 28 VDC
Constant Current Excitation：	2 to 20 mA
Settling Time (within 1% of bias)：	≤ 2.0 sec
Operating Temperature Range：	-65°F to +250 ºF (-54°C to +121 ºC)
Shock Survivability：	5,000 g pk

Competitive Advantage

Competitive Advantage 1: Wide Frequency Coverage for Early Fault Detection

The 0.5–10,000 Hz frequency range allows this accelerometer to detect both low-frequency structural issues and high-frequency bearing defects, offering broader diagnostic capability than standard automation sensors.

Competitive Advantage 2: High Measurement Accuracy and Linearity

With ±1% amplitude linearity and ≤7% transverse sensitivity, the 200350-12-00-00 accelerometer delivers precise vibration measurements, improving the reliability of automated condition monitoring and alarm systems.

Competitive Advantage 3: Exceptional Mechanical Robustness

Rated for 5,000 g peak shock and continuous operation up to 121°C, this accelerometer outperforms conventional vibration sensors in demanding automation environments, reducing replacement frequency.

Competitive Advantage 4: Low Electrical Noise for Cleaner Data

The 350 µg broadband noise level ensures high signal clarity, enabling automation analytics software to identify subtle vibration changes and improve fault diagnosis accuracy.

Competitive Advantage 5: Seamless Integration with Automation Systems

Designed for constant current excitation (2–20 mA) and 18–28 VDC supply, the 200350-12-00-00 accelerometer integrates easily with existing industrial automation and machinery monitoring platforms, minimizing installation complexity and commissioning time.
