Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
10014/H/I |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
10014/H/I |
|
Part name |
Communication Module |
|
Dimensions |
4x18.4x12.8cm |
|
Weight |
0.34kg |
|
Communication interfaces |
RS-232, RS-422, RS-485, Modbus RTU/TCP |
|
Serial data rate |
Up to 115.2 kbps |
|
Ethernet data rate |
Up to 100 Mbps (selected models) |
|
Power requirements |
5 V DC, typical current consumption ≤100 mA |
|
Operating temperature range |
-5°C to +70°C (23°F to 158°F) |
Description
The Honeywell 10014/H/I is a Communication Module. It establishes a data link between the central processor of a distributed control system and various hardware workstations, transmitting sensor readings, valve openings, and actuator control commands from the production site via digital signals.
Applications
Automotive plants: Industrial Ethernet linking stamping, welding, and assembly lines.
Semiconductor plants: Control signals between wafer tools, robots, and central controller.
Chemical plants: Pressure data from reactors and transmitters to control room.
Refineries: Valve status and pipeline flow data integration network.
Features
Redundant Architecture: Employs a dual-port design, supporting redundant communication channels to enhance system fault tolerance.
Electrical Isolation: Ports are typically electrically isolated from the power supply to prevent surge interference in industrial environments.
Diagnostic Functions: The panel is equipped with LED indicators for real-time monitoring of module status and fault diagnosis.
Safety Certifications: Complies with CE, TÜV, and UL industry standards, suitable for environments with high Safety Integrity Level (SIL).
FAQ
Q: Which mainstream industrial protocols does the 10014/H/I support?
A: It supports RS-232, RS-422, RS-485, and Modbus RTU/TCP protocols.
Q: What is the maximum serial and Ethernet speed of the 10014/H/I?
A: Serial up to 115.2 kbps and Ethernet up to 100 Mbps.
Q: What is the power consumption of the 10014/H/I during operation?
A: It uses 5 VDC with typical current below 100 mA for low heat generation.
Q: Can the 10014/H/I operate in extreme temperature environments?
A: Yes, it works from -5°C to 70°C in industrial conditions.
Q: How does the 10014/H/I achieve communication redundancy?
A: It uses a dual-port design for continuous communication even if one link fails.
