Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
05436400 MEASUREX 054364-00 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
05436400 MEASUREX 054364-00 |
|
Part name |
Logic/Termination Board |
|
Dimensions |
18.5x14x3.2cm |
|
Weight |
0.16kg |
|
Compatibility |
Industrial automation systems |
|
Operating temperature |
-40°C to +85°C |
|
Input voltage range |
12–36 VDC |
|
Output current |
Max. 50 mA per channel |
|
Communication interface |
RS-485 |
|
Power consumption |
Less than 50 mA at full load |
|
Mounting type |
Panel mount |
Description
The Honeywell 05436400 MEASUREX 054364-00 Logic/Termination Board is engineered with precision components to deliver exceptional performance in harsh industrial environments. Its robust design ensures reliable operation within wide temperature ranges, making it suitable for a variety of applications from manufacturing floors to process control systems.
Applications
Paper Mills: Aggregates sensor signals for paper machine control in high humidity and heat.
Printing Plants: Controls tension and interlocks on high-speed lines with stable communication.
Metal Processing Plants: Acts as signal terminal in production lines with wide-temperature tolerance.
Chemical Plants: Uses RS-485 bus for distributed equipment status feedback.
Power Monitoring Plants: Integrates discrete signals in distribution cabinets with compact panel mounting.
Troubleshooting and Maintenance Recommendations
Troubleshooting: If communication is abnormal, first check the matching resistor and wiring polarity of the RS-485 link; if there is no output from the channel, verify that the input voltage is within the rated range of 12-36VDC.
Maintenance Recommendations: It is recommended to regularly clean dust from the surface of the board to prevent conductive paths from forming in extreme environments; regularly check the tightness of the panel mounting screws to ensure a secure physical connection.
FAQ
Q: What is the supported power supply range for 05436400 MEASUREX 054364-00?
A: It supports a wide DC input range of 12–36 VDC for strong adaptability.
Q: What communication interface does the 05436400 MEASUREX 054364-00 use?
A: It uses RS-485 with strong noise immunity, suitable for long-distance industrial transmission.
Q: What are the temperature requirements for the 05436400 MEASUREX 054364-00?
A: It operates from -40°C to +85°C with military-grade environmental tolerance.
Q: What is the output capability and power consumption of the 05436400 MEASUREX 054364-00?
A: Each channel outputs up to 50 mA, with total consumption under 50 mA at full load.
Q: How is the 05436400 MEASUREX 054364-00 mounted and where is it used?
A: It uses panel mounting and is compatible with mainstream industrial automation systems.
