Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
HS810 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Part Number |
HS810 |
|
Product Type |
Head Station |
|
Function |
Connects PROFIBUS DP network and up to 5 power link modules for PROFIBUS PA |
|
Channels |
1-channel head station |
|
Communication Protocol |
PROFIBUS DP |
|
Data Transfer Rate |
Up to 12 Mbit/s |
|
Communication Mode |
Transparent communication, no PROFIBUS address required |
|
Baud Rate Detection |
Automatic baud rate detection (DP master independent) |
|
Device Capacity |
Supports up to 125 PA devices |
|
Configuration |
Plug-and-play, no configuration required |
|
Terminal Blocks |
Removable terminal blocks |
|
EMC Compliance |
NAMUR NE standards |
Description
The ABB HS810 is a head station for PROFIBUS DP networks. It is primarily used to connect PROFIBUS DP networks and power link modules for up to five PROFIBUS PAs. This device supports PROFIBUS DP speeds up to 12 Mbit/s.
Applications
Thermal power plants: Aggregates remote I/O data for desulfurization and denitrification monitoring via head-end stations.
Petrochemical plants: Serves as a core node for tank farm pressure and level data coordination.
Steel smelting plants: Supports blast furnace automation with strong EMI-resistant distributed communication.
District heating plants: Acts as head-end controller for heat exchange station scheduling and energy distribution.
Wastewater treatment plants: Builds stable ring-network communication for pumps and filtration process data.
Benefits
1 channel headstation- PROFIBUS DP transfer rate up to 12 MBit/s
Transparent, occupies no PRIOFIBUS address
Automatical Baud rate detection on am PROFIBUS DP- PROFIBUS master independent
Up to 125 PA-devices connectable
No configuration necessary
Removable terminal blocks-EMC acc.to NAMUR NE
FAQ
Q: Does the HS810 require a separate PROFIBUS station number?
A: No. It operates transparently as a physical-layer bridge without occupying an address.
Q: How many PA power modules can the HS810 connect?
A: Up to 5 modules, expanding the PA network.
Q: Does auto baud rate detection of the HS810 depend on the DP master?
A: No. It independently detects baud rates up to 12 Mbit/s.
Q: Does the 125-device capacity of the HS810 refer to one channel?
A: Yes. Cascaded modules support up to 125 PA devices total.
Q: What is the benefit of detachable terminals in the HS810?
A: Enables quick replacement without rewiring, reducing downtime.
